Product Introduction
01 Product Applications
THHN wire is a thermoplastic high heat-resistant nylon wire. It is also used as a machine tool wire and electrical wire specified by NEC. The THHN wire (also known as THWN-2) is rated at 600 volts and 90°C. According to TEWN, it can be used in wet or dry places.
02 Product Features
Sunlight resistance
Gas resistance
Heat resistance
Oil resistance
03 Technical Certifications
Complies with RoHS standards
UL83 standard
Product Structure
Conductor material: Bare copper or tinned copper is optional
Conductor type: Complies with UL83 standard, meets ASTM B3, B8 and B33 or NMX-J-008-ANCE requirements
Core insulation: PVC nylon coating
Core identification: Optional
Interpretation of product model:
T = Thermoplastic
HH = High heat resistance
N = Nylon coating
H = Heat resistance
W = Waterproof
Rated voltage: 600V
Test voltage: 14AWG - 2AWG: 2.0kV; 1AWG - 4/0AWG: 2.5kV; 250kcmil - 500kcmil: 3.0kV; 550kcmil - 1000kcmil: 3.5kV; 1100kcmil - 12000kcmil: 4.0kV
Conductor resistance: UL1581 ASTM Class C
Minimum bending radius for movement: 15xd
Working temperature minimum/maximum for fixed installation: -40°C/90°C
Flame retardant rating: Self-extinguishing and flame retardant properties comply with UL1581 WW-1; CSA C22.2 No.2556-15 FT1, FT2; EC 60332-1-2 standards
Certification: UL
