Product Introduction
01 Product Application
Halogen-free cross-linked stranded wires certified by UL & CUL are used for wiring in telecommunication units, electrical modules, and telecommunication facilities. This cable is a halogen-free, environmentally friendly single-core cable used for internal wiring of equipment. Signal facilities allow laying in the wall and in the pipes on the wall.
02 Product Features
It has strong resistance to acids, alkalis, and specific types of oils.
Halogen-free and flame-retardant.
It shall not be directly laid in trays, channels, or ducts (except for potential compensation).
All common standard colors are available.
03 Technical Certification
Complies with RoHS standards.
Complies with the 2014/35/EU Directive ("Low Voltage Directive") CE.
Product Structure
Conductor material: Bare copper
Conductor type: Complies with UL758 standards and Class 5 of IEC60228.
Core insulation: XLPE
Core identification: Different colors
Rated voltage: 1000V
Test voltage: 3000V;
Conductor resistance: UL1581 ASTM Class C
Minimum bending radius for fixed installation: 4xd
Minimum bending radius for movable installation: 15xd
Working temperature for fixed installation, minimum/maximum: -40°C/125°C
Halogen-free property complies with IEC 60754
Smoke density complies with IEC61034
Flame-retardant rating: Self-extinguishing and flame-retardant, complies with IEC60332-1-2, FT2
Standards: UL758, CE
Product identification: E503807 Brother AWM Model Specification Temperature Voltage or C Brother AWMIA Specification Temperature Voltage FT2 SHANGHAI AEIN
