Product Introduction
01 Product Application
It is a communication cable with North American fire protection grade. The core application scenarios are concentrated in the static pressure area of building ventilation and air - conditioning airflow. It is also widely used in public buildings and data centers with extremely high safety standards.
02 Product Features
Fire - resistant, flame - retardant, and can prevent the upward spread of flames. It complies with North American building codes and can be directly used for static pressure wiring. It has low smoke density, does not block the line of sight, and facilitates personnel evacuation.
03 Technical Certifications
Complies with RoHS standards
Complies with CSA certification
Complies with UL444
Structure Specifications
Conductor material: Single or multi - strand stranded conductors
Core insulation: FEP
Core identification: Brown, white/brown, blue, white/blue, orange, white/orange, green, white/green
Stranding: 2 cores are twisted into a pair; wire pairs are stranded in layers
Outer sheath: PVC
Sheath color: Select according to requirements
Test voltage: 300V
Minimum bending radius: Fixed 8xd
Temperature grade: -15°C/+60°C, -15°C/+70°C
Standard: CSA C22.2/UL444
Product identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO.LTD Model Specification Voltage CSA meter mark
