Product Introduction
01 Product Application
It is a cable specifically designed for vertical trunk scenarios in the North American NEC specification. It is mostly used for wiring in building vertical shafts, weak current wells, elevator shafts, horizontal trunks in non-airflow channels, and multi-floor public buildings.
02 Product Features
Flame retardant, preventing the upward spread of flames. It is a cable specifically designed for vertical trunk scenarios in the North American NEC specification. It is mostly used for wiring in building vertical shafts, weak current wells, elevator shafts, horizontal trunks in non-airflow channels, and multi-floor public buildings.
03 Technical Certifications
Complies with RoHS standard
Complies with CSA certification
Complies with UL444
Structural Specifications
Conductor material: Single or multi-stranded twisted conductors
Core insulation: FEP
Core identification: Brown, white/brown, blue, white/blue, orange, white/orange, green, white/green
Twisting: Two cores are twisted into a pair; wire pairs are twisted in layers
Outer sheath: PVC
Sheath color: Choose according to requirements
Test voltage: 300V
Minimum bending radius: Fixed 8xd
Temperature rating: -15°C/+60°C, -15°C/+70°C
Standard: CSA C22.2/UL444
Product identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO.LTD Model Specification Voltage CSA meter mark
