Product Introduction
01 Product Applications
Used in energy networks with fire risks in hotels, schools, tunnels, high-rise buildings, hospitals, power plants, data processing, and commercial areas. These cables with low dielectric loss and mechanical resistance are mainly used in energy networks in residential or industrial areas with sudden load changes. They can be laid outdoors, underground, and in areas where sudden mechanical stress is expected.
02 Product Features
Flame retardancy complies with IEC60332-1-2
Non-flammability performance complies with IEC60332-3-24
Halogen-free complies with IEC60754-1:2011 (total amount of halogen acid gas)
Corrosiveness of combustion gas complies with IEC60754-2:2011 (acidity)
Low smoke density, complies with IEC61034-2:2005+A12013+A2:2020
03 Technical Certifications
Complies with RoHS standard
Complies with 2014/35/EU - Directive "Low Voltage Directive") CE
Product Structure
Conductor material: Bare copper wire
Conductor class: Complies with IEC60228 cl.5 standard, cl.2 is optional
Insulation: XLPE
Core identification: Black cores with white numbers, with or without GNYE
Stranding: Layered stranding
Outer sheath: Halogen-free, thermoplastic polyolefin mixture
Sheath color: Black, RAL9005 or gray RAL7001
Rated voltage: 0.6/1kV
Test voltage: 3.5kV
Conductor resistance: Complies with IEC 60228 cl.5 standard
The rated temperature of the cable conductor is: 90°C
During short-circuit (long duration not exceeding 5s), the cable conductor temperature does not exceed 250°C
Minimum bending radius for fixed installation: 7.5xd
Minimum bending radius for movable installation: 15xd
Temperature rating for fixed installation: -25°C/+90°C
Temperature rating for movable installation: -25°C/+90°C
Flame retardant rating: IEC60332-1-2
Standards: HD 603-3G IEC60502-1
Product Identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO.LTD Model, Specification, Voltage, CE, Meter Mark
