Product Introduction
01 Product Application
Cables for connecting servo controllers and motors
Suitable for static and occasional flexible use
Suitable for indoor and outdoor installation, air supports, pipes, or direct burial
02 Product Features
Low capacitance
Flammability:
UL/CSA: WW-1, FT1
IEC/EN: 60332-1-2
03 Technical Certification
Complies with RoHS standards
Customization is acceptable for products with special structures, other sizes, and colors of core wires and sheaths.
Product Structure
Conductor material: Fine, bare copper conductors
Conductor grade: Complies with EN60228 standard
Core wire insulation: XLPE
Stranding: Concentric insulated wires
Shielding: 0.10 mm thick copper tape, complies with IEC-60502, overlap > 20%
Outer sheath: Halogen-free polyolefin
Outer sheath color: Specifiable color
Rated voltage: 600/1000V
Test voltage: 3500V
Conductor resistance: UL1581 ASTM Class C
Minimum bending radius (fixed): 6xd
Minimum bending radius (movable): 15xd
Working temperature (fixed, min/max): -40°C/+90°C
Temperature grade (movable, min/max): -5°C/+70°C;
