Help CenterCompact Tubular Three-Effect Evaporator With Vacuum System, PLC Touch Screen, Working Pressure ≤0.5MPa
Product Spotlights
Related Products
-
Reliable Tubular Three-Effect Evaporator, Mill Test Report Provided, On-Site Commissioning Support, 1T/H CapacityUS$ 2560 - 896000MOQ: 2 Combos -
Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/HUS$ 2560 - 896000MOQ: 2 Combos
-
Tubular Three-Effect Evaporator With Integrated Condenser, Energy Recovery, 304 SS, 1000L/H CapacityUS$ 2560 - 896000MOQ: 2 Combos
-
Tubular Three-Effect Evaporator for Food Processing, Concentrating Juice and Milk, 304 Stainless Steel, Automatic OperationUS$ 2560 - 896000MOQ: 2 Combos
-
304 Stainless Steel Tubular Three-Effect Evaporator With PLC Automatic Control, Evaporation Capacity 500L/HUS$ 2560 - 896000MOQ: 2 Combos
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – your reliable partner in advanced evaporation solutions. As a manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters and an annual export value exceeding US$10 million, we are proud to introduce our Compact Tubular Three-Effect Evaporator with Vacuum System and PLC Touch Screen. This high-efficiency system is designed to handle demanding concentration and evaporation tasks with minimal energy consumption, thanks to its three-effect design and integrated vacuum technology. The working pressure is safely maintained at ≤0.5 MPa, ensuring stable operation and long equipment life. Whether you are treating industrial wastewater, concentrating chemical solutions, or processing food products, this evaporator delivers consistent performance and ease of control through its intuitive PLC touch screen interface.
Key Features & Technical Specifications
- Three-Effect Evaporation Design – Maximizes energy utilization by recovering latent heat from each stage. Compared to single-effect systems, energy savings can reach up to 60-70%.
- Integrated Vacuum System – Lowers boiling point of the liquid, allowing gentler evaporation for heat-sensitive materials and reducing scaling/fouling.
- PLC Touch Screen Control – User-friendly interface provides real-time monitoring of temperature, pressure, flow rate, and system status. Automatic alarm and safety shutdown features ensure worry-free operation.
- Compact Tubular Design – Occupies minimal floor space while offering high heat transfer efficiency. Modular construction simplifies installation and maintenance.
- Working Pressure ≤0.5 MPa – Designed with safety margins to handle typical industrial steam supplies, compliant with international pressure vessel standards (available upon request).
- Corrosion-Resistant Materials – Standard construction in SS304 or optional SS316L for aggressive chemical environments.
- Flexible Capacity Options – Evaporation capacity can be customized according to your specific process requirements (typically from 500 L/h to 5000 L/h).
Technical Parameters (Example)
| Parameter | Value |
|---|---|
| Evaporation Capacity | 1000 L/h (customizable) |
| Number of Effects | 3 |
| Working Pressure (Steam Side) | ≤0.5 MPa |
| Vacuum Degree | -0.08 ~ -0.095 MPa |
| Operating Temperature | 60–100°C (depending on vacuum and liquid) |
| Power Supply | 380V/50Hz, 3-phase (other voltages available) |
| Control System | PLC + 7-inch Touch Screen |
| Material | SS304 (SS316L optional) |
Benefits for Your Business
- Lower operating costs – Three-effect design reduces steam consumption by up to 70% compared to single-effect units.
- Enhanced product quality – Low-temperature evaporation in vacuum preserves sensitive ingredients and reduces thermal degradation.
- Simplified maintenance – Tubular heat exchangers are easy to clean and inspect; modular design allows quick replacement of individual components.
- Smart automation – PLC with touch screen reduces manual intervention, stores multiple recipes, and provides data logging for quality control.
- Scalability – Multiple units can be combined for higher capacity; our engineers can design a complete turnkey system for your plant.
Why Choose Qingdao Conqinphi Environmental Technology Group?
Backed by over 200 employees and a modern manufacturing facility, we have delivered evaporation solutions to clients across North America, South America, Europe, Asia, Africa, and Oceania. Our products are manufactured under strict quality management systems (ISO9001, ISO14000, OHSAS18001, and many others) to ensure reliability and safety. With an annual export value between US$10 million and US$50 million, we have the capacity and experience to meet large-scale orders promptly. Every evaporator undergoes rigorous testing before shipment from Qingdao Port. We also offer comprehensive after-sales support including remote diagnostics, spare parts availability, and on-site commissioning assistance. Invest in a machine that will serve your production line for years to come. Contact us today for a tailored quotation or technical consultation.
Frequently Asked Questions
-
Q1: What is the typical payback period for this three-effect evaporator?
A: Depending on your energy costs and throughput, many clients see a payback within 12–18 months due to steam savings. Our sales team can provide a detailed ROI analysis based on your specific parameters. -
Q2: Can this evaporator handle high-viscosity liquids?
A: Yes, the tubular design can handle moderate viscosity liquids (up to about 1000 cP). For extremely viscous products, we recommend a forced-circulation configuration, which is available as an option. -
Q3: What certifications does the equipment have?
A: Our factory holds multiple system certifications (e.g., ISO9001, ISO14000, OHSAS18001). The evaporator can be designed to meet ASME, PED, or GB standards upon request. Please specify your required standard during inquiry. -
Q4: How is the PLC touch screen programmed?
A: It comes pre-programmed with common process parameters. You can easily modify setpoints, alarm thresholds, and create custom recipes through the touch screen. We also provide training manuals and remote support. -
Q5: What is the maintenance frequency?
A: We recommend a quick internal inspection every 3 months and a full service every 12 months. The tubular heat exchangers are less prone to fouling; cleaning-in-place (CIP) can be integrated. -
Q6: Can the working pressure be higher than 0.5 MPa?
A: The standard design is ≤0.5 MPa. For higher pressure requirements (e.g., up to 1.0 MPa), we can customize the heat exchanger and pressure vessel. Contact our engineering team for feasibility. -
Q7: What is the warranty period?
A: We offer a standard 12-month warranty from the date of commissioning. Extended warranty plans are available upon request. -
Q8: Do you provide installation and training?
A: Yes, we can send our engineers to your site for installation supervision and operator training. Alternatively, we offer remote video guidance. Terms are negotiable.
Ready to optimize your evaporation process? Leave us a message with your requirements, and we will respond within 24 hours with a competitive offer. Join hundreds of satisfied customers worldwide who trust Qingdao Conqinphi for their environmental and process equipment.
