Help CenterTriple-effect Vacuum Evaporator Compact Design Vacuum Pump Condenser Integrated no Leakage Sealed
Product Spotlights
Related Products
-
Triple-effect Vacuum Evaporator 1 Year Warranty Free Installation Guidance Technical Support ProvidedUS$ 1000 - 165000MOQ: 1 Combo -
Triple-effect Vacuum Evaporator for Pharmaceutical Industry 304 SS Complies With GMP StandardsUS$ 1000 - 165000MOQ: 1 Combo
-
Triple-effect Vacuum Evaporator for Chemical Concentration Solution Recovery Solvent Separation IndustrialUS$ 1000 - 165000MOQ: 1 Combo
-
Triple-effect Vacuum Evaporator 316L SS Shell Touch Screen 380V 3-phase 200L/h EvaporationUS$ 1000 - 165000MOQ: 1 Combo
-
Triple-effect Vacuum Evaporator Factory Direct After-sales Service Customer Training IncludedUS$ 1000 - 165000MOQ: 1 Combo
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – your trusted partner for advanced environmental solutions. Our Triple-effect Vacuum Evaporator with Compact Design, Integrated Vacuum Pump, Condenser, and No-Leakage Sealed System represents a breakthrough in efficiency and reliability. Designed to handle challenging wastewater streams, this unit combines three evaporation stages into a single, space-saving unit, drastically reducing energy consumption while maximizing water recovery. The integrated vacuum pump and condenser eliminate external piping, minimizing leakage points and ensuring a safe, clean operation. Whether you are treating industrial effluents or concentrating valuable solutions, this evaporator delivers consistent performance with minimal maintenance.
Why choose our triple-effect vacuum evaporator? Traditional single-effect evaporators consume enormous energy; our triple-effect design reuses vapor from one stage as the heating medium for the next, achieving up to 60% energy savings. The compact, fully sealed construction not only saves valuable floor space but also prevents harmful emissions, meeting modern environmental standards. Each unit is engineered with precision, backed by our factory’s 10,000-30,000 m² facility and a dedicated R&D team. With annual export value exceeding US$10 million, we serve clients across North America, Europe, Asia, and beyond.
Key Features & Technical Specifications
| Feature | Specification / Benefit |
|---|---|
| Design | Triple-effect evaporation, integrated vacuum pump & condenser, compact footprint |
| Material | Optionally SS304 or SS316 for corrosion resistance |
| Capacity | Customizable from 50 L/h to 500 L/h (larger available upon request) |
| Energy Consumption | Up to 60% lower than single-effect units |
| Seal System | Fully sealed design – zero leakage, no fugitive emissions |
| Operation | Automatic control, low maintenance, easy integration |
| Applications | Industrial wastewater (chemical, pharmaceutical, food & beverage), landfill leachate, metal finishing |
Product Advantages & Customer Benefits
- Energy Efficiency: Triple-effect design recovers latent heat, reducing steam/electricity costs by 50-70%.
- Space Saving: Compact layout integrates pump and condenser – ideal for plants with limited floor area.
- Environmentally Safe: No leakage means no vapor escape, protecting operators and meeting strict emission regulations.
- Low Maintenance: Fewer connections and seals result in less wear and tear; easy access for cleaning.
- Versatile: Handles acidic, alkaline, and high-salinity solutions; customizable for specific pH and temperature ranges.
- Reliable Performance: Built with high-quality stainless steel and industrial-grade components, ensuring long service life.
How it works: The triple-effect system operates under vacuum to lower boiling points. Feed liquid enters the first effect, where it is heated by steam. The generated vapor then goes to the second effect, transferring heat to concentrate the liquid further. This process repeats in the third effect, maximizing concentration while minimizing energy input. The integrated vacuum pump maintains consistent negative pressure, and the sealed condenser recovers distillate efficiently.
Trust & Credibility
As a manufacturer established in 2015, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has grown into a 201-300 employee strong enterprise with a 10,000-30,000 m² factory in Qingdao, China. We export US$10-50 million annually to markets spanning North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and beyond. Our quality management system is certified to ISO9001, ISO14000, OHSAS18001, and other international standards (available upon request). We offer customizable solutions for your specific wastewater challenges, with full technical support and after-sales service. Contact us today for a detailed proposal, performance data, or a factory visit. Let us help you turn waste into value – efficiently, safely, and sustainably.
Frequently Asked Questions
Q1: What is the typical payback period for this triple-effect evaporator?
A: Depending on your energy costs and throughput, many clients see payback within 1-2 years due to the significant energy savings compared to single-effect systems.
Q2: Can it handle highly corrosive wastewater?
A: Yes, we offer optional SS316 or other specialized alloys, and we can also apply anti-corrosion coatings. Please provide your liquid composition for a tailored recommendation.
Q3: Is the system fully automatic?
A: Yes, the evaporator comes with a PLC-based control panel for automatic operation, including start/stop, temperature control, and alarm functions. Manual override is available.
Q4: What maintenance is required?
A: Routine maintenance includes periodic cleaning of the heat exchange surfaces (depending on scaling tendency), checking seals, and lubricating pumps. Detailed manual provided.
Q5: How compact is the design exactly? Can it fit in a 10 ft container?
A: The basic module (up to 200 L/h) can be skid-mounted and fits inside a standard 20 ft container. For larger capacities, please contact us for dimensions.
Q6: What after-sales support do you offer?
A: We provide remote technical support, spare parts supply, and optional on-site commissioning assistance. Our team responds within 24 hours.
Q7: Do you have test data for specific waste streams?
A: We have tested various liquids including pharmaceutical mother liquor, electroplating rinse water, and landfill leachate. We can provide case studies or conduct pilot tests at our facility.
Q8: Can the system be customized for different voltages or frequencies?
A: Absolutely. We design for 380V/50Hz as standard, but we can adapt to 220V/60Hz or other requirements upon request.
