Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd., a professional manufacturer established in 2015 with a factory area of 10,000-30,000 square meters and an annual export value of US$10-50 million. We proudly introduce our High Efficiency Tubular Three-Effect Evaporator – a cutting-edge solution designed for efficient concentration and wastewater reduction. Constructed from premium 316L stainless steel and equipped with automatic CIP cleaning, this evaporator delivers reliable performance, energy savings, and low maintenance for demanding industrial processes.
Product Overview
Our tubular three-effect evaporator utilizes a triple-stage evaporation design to maximize heat recovery and minimize energy consumption. The 316L stainless steel construction ensures excellent corrosion resistance and longevity, even when processing aggressive or acidic feed solutions. With a capacity range of 1 to 5 tons per hour, the system can be tailored to meet specific production requirements. The integrated Auto-CIP (Clean-in-Place) system reduces downtime and manual cleaning effort, maintaining hygiene and process efficiency.
Key Features & Technical Specifications
- Three-Effect Design: Each effect operates at a lower boiling point, utilizing vapor from the previous effect as heating medium. This saves up to 60% energy compared to single-effect evaporators.
- 316L Stainless Steel: All wetted parts are made of 316L SS, providing outstanding resistance to chloride stress corrosion and pitting.
- Auto-CIP Cleaning: Automated spray nozzles and recirculation loops clean internals without disassembly, reducing labor costs and ensuring consistent product quality.
- Wide Capacity Range: Standard models cover 1 T/H, 2 T/H, 3 T/H, 4 T/H, and 5 T/H evaporation rates. Custom rates available upon request.
- Modular Construction: Pre-assembled skid-mounted design for quick installation and easy integration into existing lines.
- Advanced Control System: PLC with HMI interface monitors temperature, pressure, flow, and level, enabling remote operation and data logging.
- Low Operating Pressure: Vacuum operation allows processing of heat-sensitive materials at reduced temperatures (typically 50-80°C).
Typical Technical Parameters
| Parameter | Value |
|---|---|
| Model | QCE-T3E-1 to QCE-T3E-5 |
| Evaporation Capacity | 1, 2, 3, 4, 5 T/H (nominal) |
| Material of Construction | 316L Stainless Steel (SUS316L) |
| Number of Effects | 3 |
| Operating Temperature | 50–80°C (under vacuum) |
| Vacuum Degree | -0.08 to -0.095 MPa |
| Steam Consumption | Approx. 0.35–0.45 kg steam per kg water evaporated |
| Power Consumption | 15–45 kW (depending on capacity) |
| CIP System | Automatic, with tank and pump included |
| Control | PLC + Touch Screen (optional remote monitoring) |
| Dimensions (L×W×H) | Varies by model (approx. 6m×2.5m×4m for 3 T/H) |
Advantages for Your Business
- Lower Operating Costs: Triple-effect heat integration reduces steam consumption significantly, leading to lower energy bills.
- Minimal Downtime: Auto-CIP cleaning eliminates the need for manual disassembly, reducing cleaning time by 80%.
- Extended Equipment Life: 316L SS resists corrosion from chlorides, acids, and alkalis, prolonging service intervals.
- Flexible Processing: Suitable for wastewater concentration, chemical evaporation, pharmaceutical liquid concentration, food juice concentration, etc.
- Easy Integration: Compact skid design with pre-piped and pre-wired components simplifies on-site installation.
- Compliance Support: Our factory follows ISO9001 and HACCP standards; optional certifications available per request.
Why Choose Qingdao Conqinphi?
With over 8 years of manufacturing experience, a 10,000-30,000 m² facility, and a team of 201-300 skilled employees, we have exported to markets across North America, South America, Europe, Asia, Africa, and Oceania. Our annual export value exceeds US$10 million, reflecting global trust in our products. We hold multiple certifications including ISO9001, HACCP, and others, ensuring each evaporator meets rigorous quality standards.
Our engineers provide end-to-end support: from process design, customization, manufacturing, to installation and commissioning. Every unit undergoes strict inspection before shipment. When you choose our High Efficiency Tubular Three-Effect Evaporator, you invest in reliability, performance, and long-term partnership.
Contact us today for a quote or technical consultation. Let us help optimize your evaporation process!
Frequently Asked Questions
- What is the working principle of a three-effect evaporator? It uses steam to heat the first effect; the vapor generated heats the second effect at lower pressure, and so on. This cascading reuse of heat energy reduces total steam consumption.
- What types of feed materials can be processed? It is suitable for aqueous solutions, including wastewater, chemical liquors, fruit juices, milk, pharmaceutical extracts, and more. For high-viscosity or scaling fluids, customization may be required.
- How does the Auto-CIP system work? The system automatically circulates cleaning solution (e.g., caustic and acid) through the evaporator tubes and chambers, followed by rinsing, without disassembly. It can be programmed based on your schedule.
- Can the capacity be customized for less than 1 T/H or more than 5 T/H? Yes, we offer custom designs for capacities from 0.5 T/H up to 10 T/H or higher, depending on your process parameters.
- What is the typical energy saving compared to single-effect? A three-effect evaporator typically saves 50-60% of steam consumption compared to a single-effect system. Exact savings depend on operating conditions.
- What after-sales support do you provide? We offer remote troubleshooting, spare parts supply, on-site commissioning guidance, and optional annual maintenance contracts.
- What certifications does your factory hold? Our quality management system is certified to ISO9001, and we also comply with HACCP standards. Additional certifications can be provided based on customer requirements.
- How long does delivery take? Standard models are typically delivered within 45-60 days after order confirmation; custom units may take 60-90 days.
