Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/H

Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/H thumbnail-3

Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/H thumbnail-4

Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/H thumbnail-5

Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/H photo-1

Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/H photo-2

Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/H photo-3

Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/H photo-4

Tubular Three-Effect Evaporator With 1-Year Warranty and Free Installation Guide, 304 SS, PLC Control, 0.5T/H photo-5

Product Spotlights

1. 304 SS construction ensures long-term corrosion resistance. 2. PLC control for precise automation and reduced labor. 3. Three-effect design cuts energy consumption by up to 60%. 4. Free installation guide simplifies setup. 5. 1-year warranty with dedicated after-sales support. 6. Customizable for various industrial fluids.

US$ 2560 - 896000 MOQ: 2 Combos

Key Specifications

Get Latest Price

Warranty:

1 Year

Certification:

Other, ISO9001

Material:

304 Stainless Steel

Contact Supplier Request Quote Chat Now

Qingdao Conqinphi Environmental Technology Group Co., Ltd.

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

20 days

Product Details
Company Profile
Contact Us

Warranty 1 Year

Certification Other, ISO9001

Material 304 Stainless Steel

Evaporation Capacity 0.5 T/H

Control System PLC Control

Number of Effects Three Effects

Type Tubular

Installation Guide Free Installation Guide Provided

Application Industrial Wastewater Treatment, Chemical Processing

Power Supply 380V/220V (Customizable)

Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. As a professional manufacturer with over a decade of experience in environmental equipment, we are proud to introduce our Tubular Three-Effect Evaporator. Designed for high-efficiency concentration and evaporation, this system is constructed from 304 stainless steel to ensure durability and corrosion resistance, even in demanding industrial environments. With a PLC control system and a processing capacity of 0.5 tons per hour, this evaporator offers precise automation, reduced energy consumption, and consistent performance. We back every unit with a 1-year warranty and provide a free installation guide to help you get started quickly and smoothly.

Product Features and Technical Specifications

Robust Three-Effect Design: Utilizing three evaporation stages to maximize heat recovery and minimize energy usage, resulting in lower operating costs.
Premium 304 Stainless Steel Construction: All wetted parts are made of high-grade 304 SS, offering excellent resistance to acids, alkalis, and salts for long service life.
Advanced PLC Control: Programmable logic controller with touchscreen interface enables real-time monitoring, automatic adjustments, and remote operation capability.
High Evaporation Capacity: 0.5 tons per hour (500 L/h) suitable for small to medium-scale industrial processes such as wastewater treatment, food concentration, or chemical recovery.
Easy Installation and Maintenance: Compact tubular design with accessible components. The free installation guide includes step-by-step instructions, diagrams, and troubleshooting tips.
Energy Efficient: The three-effect system reduces steam consumption by up to 60% compared to single-effect evaporators.
Customizable Options: Additional features like CIP (clean-in-place) system, vacuum pump, or different voltage configurations are available upon request.

Detailed Parameters

Parameter	Specification
Model	Tubular Three-Effect Evaporator
Material	304 Stainless Steel
Evaporation Capacity	0.5 T/H (500 L/H)
Number of Effects	Three
Control System	PLC with Touchscreen
Power Supply	380V / 3Ph / 50Hz (Customizable)
Warranty	1 Year
Installation Support	Free Installation Guide Included

Why Choose Our Tubular Three-Effect Evaporator?

Reliability: Manufactured in our ISO9001 and ISO14000 certified facility, ensuring consistent quality and environmental responsibility.
Global Experience: With annual export value exceeding US$10 million, our equipment is trusted by clients across North America, South America, Europe, Southeast Asia, Africa, and the Middle East.
Expert Team: Our 200+ employees include skilled engineers and technicians dedicated to R&D, production, and after-sales support.
Comprehensive Certifications: Our products meet HACCP, OHSAS18001, and multiple ISO standards, demonstrating commitment to safety, quality, and hygiene.
Factory Scale: Operating from a 10,000–30,000 sqm factory in Qingdao, China, we have the capacity to deliver large orders on time.

Trusted by Industries Worldwide

Since 2015, Qingdao Conqinphi Environmental Technology Group has been a leading manufacturer in the environmental sector. Our Tubular Three-Effect Evaporator is the result of continuous innovation and customer feedback. Backed by a 1-year warranty and a free installation guide, this evaporator provides a reliable solution for reducing wastewater volume, recovering valuable by-products, and meeting discharge regulations. With our strong export history and a broad network of satisfied customers, we invite you to experience the performance and durability of our equipment. Contact us today for a quote or technical consultation!

Frequently Asked Questions (FAQ)

What materials can be processed with this evaporator? It is suitable for aqueous solutions such as industrial wastewater, brine, and food concentrates. Please consult our engineers for specific compatibility.
Does the unit come with a control panel? Yes, it includes a PLC-based control panel with a touchscreen interface for easy operation.
What is the recommended maintenance schedule? Regular inspection of seals, pumps, and tubes every 3–6 months is suggested. The installation guide provides detailed procedures.
Can the evaporator handle corrosive liquids? The 304 SS construction offers good corrosion resistance for many applications. For highly corrosive media, optional upgrades like 316L SS are available on request.
Is the installation guide sufficient for self-installation? Yes, the guide includes step-by-step instructions, wiring diagrams, and safety precautions. However, we recommend professional installation for optimal performance.
What does the 1-year warranty cover? It covers manufacturing defects in materials and workmanship. Consumables and damages due to improper use are not included.
How energy efficient is this system compared to single-effect units? The three-effect design can reduce steam consumption by up to 60%, leading to significant operational savings.
Can I get a customized capacity or configuration? Absolutely. We offer customization options including different evaporation capacities, voltage requirements, and additional automation features. Contact our sales team.
