At Qingdao Conqinphi Environmental Technology Group Co., Ltd., we leverage over a decade of manufacturing expertise (est. 2015) and a factory spanning 10,000–30,000 square meters to deliver robust industrial solutions. Our Energy Saving Tubular Three-Effect Evaporator with 220V electric heating and 304 SS construction is engineered for concentrated evaporation of wastewater, chemicals, and food products. With a capacity range of 0.5 to 2 T/H, it offers outstanding energy efficiency—reducing steam consumption by up to 70% compared to single-effect units—while maintaining high throughput. This evaporator is designed to lower your operational costs and environmental footprint, backed by our annual export value of US$10–50 million across global markets including North America, Europe, and Asia.
Our tubular three-effect design utilizes the latent heat from vapor generated in each effect to preheat and evaporate the feed in subsequent stages. The 304 stainless steel construction ensures excellent corrosion resistance and longevity, even when processing aggressive media. The 220V electric heating system provides convenient, clean, and precise temperature control without the need for a separate boiler, making it ideal for facilities with limited steam infrastructure. Standard models support capacities from 0.5 to 2 T/H, but we offer customization for specific volume and concentration requirements.
Key Features & Technical Specifications
- Triple-Effect Energy Recovery: Achieves up to 70% energy savings compared to single-effect evaporation.
- 304 Stainless Steel Construction: All wetted parts are made of 304 SS, offering excellent resistance to corrosion and easy cleaning.
- 220V Electric Heating: Plug‑and‑play operation; no steam boiler required; suitable for remote or small‑scale installations.
- Wide Capacity Range: Available in 0.5, 1.0, 1.5, and 2.0 T/H configurations; adjustable via control system.
- Compact Tubular Design: Space‑saving footprint with vertical heat exchanger arrangement, facilitating easy installation and maintenance.
- Automated Control: PLC touch‑screen interface for temperature, pressure, and flow monitoring; optional remote monitoring.
- High Evaporation Efficiency: Evaporation rate up to 95% with proper pre‑treatment; suitable for concentration ratios up to 10:1.
- Versatile Applications: Ideal for industrial wastewater, pharmaceutical extracts, food concentrates, and chemical solutions.
| Parameter | Value / Range |
| Model | CQ-TE-05~20 |
| Evaporation Capacity | 0.5 – 2.0 T/H |
| Material | 304 Stainless Steel (Optional: 316L) |
| Heating Method | Electric Heating, 220V / 50-60Hz |
| Number of Effects | Three |
| Operating Temperature | 70°C – 120°C (adjustable) |
| Operating Pressure | -0.09 MPa to +0.2 MPa |
| Energy Consumption | Approx. 30% of single-effect system |
| Control System | PLC + HMI (optional remote access) |
| Certifications | ISO9001, ISO14001, OHSAS18001, etc. |
Beyond the technical advantages, our evaporator delivers tangible business benefits: lower utility bills due to reduced electricity or steam consumption, minimized waste volume that cuts disposal costs, and reliable compliance with environmental regulations. The 304 SS construction also facilitates CIP (Clean‑in‑Place) procedures, reducing downtime and maintenance labor. All units undergo stringent quality control before shipment.
Backed by our 201–300 dedicated employees and a factory with advanced manufacturing capabilities, we have delivered evaporators to clients in over 30 countries including Germany, Brazil, Saudi Arabia, and South Korea. Our quality management system holds multiple certifications including ISO9001, ISO14001, and OHSAS18001, ensuring each product meets international standards. We offer comprehensive after‑sales support: installation guidance, operator training, and spare parts availability. With an annual export value exceeding US$10 million, our track record speaks for itself. Choose Qingdao Conqinphi for a reliable, energy‑efficient evaporation solution tailored to your process. Contact our team today for a free technical consultation or quotation.
Frequently Asked Questions (FAQ)
- What is a three-effect evaporator? A three-effect evaporator uses three stages (effects) where the vapor from the first effect heats the second, and so on, dramatically reducing energy consumption compared to single-effect designs.
- How much energy can I save? Typically 60–70% less steam or electricity consumption than a single-effect unit, depending on feed characteristics and operating conditions.
- What industries is this evaporator suitable for? It is widely used in industrial wastewater treatment, food concentration (e.g., juices, dairy), pharmaceutical extraction, and chemical processing (e.g., salt recovery, acid concentration).
- Can I use it without a steam boiler? Yes – our 220V electric heating model requires no steam boiler, making it ideal for facilities with limited utility infrastructure or strict emissions regulations.
- What maintenance is required? Routine inspection of seals, heating elements, and cleaning of tube surfaces (CIP recommended). The 304 SS material minimizes scaling and corrosion. We provide a detailed maintenance manual.
- What is the delivery time? Standard models (0.5–2 T/H) typically ship within 30–45 days after order confirmation. Customized solutions may require 45–60 days depending on complexity.
- Can you customize the capacity or material? Absolutely. We offer capacities up to 5 T/H and can upgrade to 316L stainless steel or other alloys upon request. Contact our sales team with your process conditions.
- Do you provide installation and training? Yes – we supply installation drawings, on‑site guidance (optional), and operator training. Remote technical support is also available 24/7.
