Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 and headquartered in Qingdao, Shandong, China, is a professional manufacturer specializing in environmental treatment equipment. With a factory area spanning 10,000–30,000 square meters and an annual export value exceeding US$10 million, we serve clients across North America, Europe, Asia, and Oceania. Our 220V 15kW Skid-Mounted Evaporator with Automatic Feed System and IP65 Enclosure is designed to deliver reliable, efficient liquid concentration and wastewater reduction in demanding industrial environments. This all-in-one solution combines rugged construction, smart automation, and environmental protection for continuous operation.
Core Features & Benefits
- Compact Skid-Mounted Design – The entire system is mounted on a heavy-duty skid, allowing for quick installation, easy relocation, and minimal footprint. No permanent foundation required.
- Automatic Feed System – Equipped with a level-controlled feed pump and PLC-based logic, the evaporator automatically maintains optimal liquid levels, reducing operator intervention and ensuring stable performance.
- IP65 Enclosure – The electrical cabinet and key components are housed in an IP65-rated enclosure, protecting against dust ingress and water jets. Suitable for outdoor or harsh indoor environments.
- 220V / 15kW Heating Power – Operates on standard 220V single-phase or three-phase power, delivering 15kW of heating capacity for efficient evaporation of water and solvents.
- High-Quality Construction – The evaporator body is made of stainless steel 304, offering excellent corrosion resistance and longevity. All wetted parts are designed for easy cleaning and maintenance.
- PLC Control with HMI (Optional) – The system can be upgraded with a touch-screen HMI for real-time monitoring of temperature, pressure, feed rate, and alarms. Remote monitoring capability available upon request.
- Energy-Efficient Operation – Optional heat recovery and vapor condensation modules can be integrated to reduce overall energy consumption.
Technical Specifications (Typical)
| Parameter | Value |
| Power Supply | 220V, 50/60Hz (single or three phase) |
| Heating Power | 15 kW |
| Evaporation Capacity | Approx. 20–30 L/h (depends on liquid properties) |
| Feed System Type | Automatic level-controlled pump |
| Enclosure Protection | IP65 |
| Wetted Materials | Stainless Steel 304, PTFE seals |
| Control System | PLC with optional HMI |
| Operating Temperature | Up to 120°C (adjustable) |
| Dimensions (L×W×H) | Approx. 1800×1200×1600 mm (customizable) |
| Weight | Approx. 650 kg |
Why Choose Our Skid-Mounted Evaporator?
- Proven Reliability – Manufactured under ISO9001 quality management system and supported by our 9 years of experience in environmental equipment production.
- Global Shipping & Support – Shipped from Qingdao Port with professional export packing. We offer technical documentation, after-sales support, and spare parts availability.
- Customizable Options – Optional add-ons include heat recovery, condensate polishing, remote monitoring, and different voltage configurations for global markets.
- Low Maintenance – Few moving parts, easy-access design, and durable materials reduce downtime and operating costs.
- Energy Saving – The automatic feed system prevents dry running and optimizes energy use, while optional vapor recompression can cut energy consumption by up to 30%.
Company Strength & Trustworthiness
As a manufacturer with over 200 employees and a factory area of 10,000–30,000 square meters, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has exported to more than 30 countries and regions, including North America, Europe, Southeast Asia, and Oceania. Our products carry certifications such as ISO9001, ISO14000, OHSAS18001, and HACCP, reflecting our commitment to quality, environment, and safety. We have served numerous clients in the chemical, pharmaceutical, food processing, and metal finishing industries. Our dedicated engineering team can tailor the evaporator to meet specific process requirements.
Frequently Asked Questions
-
Q: Can this evaporator handle corrosive liquids?
A: Yes, the standard construction uses SS304, which is suitable for many aqueous solutions. For highly corrosive media, optional SS316L or special coatings are available. -
Q: What is the typical evaporation capacity for water?
A: Under normal conditions, the unit can evaporate approximately 20–30 liters of water per hour. Actual capacity depends on feed concentration, ambient temperature, and desired final concentration. -
Q: Is the IP65 enclosure suitable for outdoor installation?
A: Absolutely. IP65 provides protection against dust and low-pressure water jets, making it ideal for outdoor use. Additional weatherproofing options are available for extreme climates. -
Q: Do you provide installation and commissioning support?
A: Yes, we offer remote guidance and can arrange on-site commissioning upon request. Detailed manuals and wiring diagrams are included. -
Q: What is the lead time for this model?
A: Standard lead time is approximately 25–35 working days after order confirmation. Custom configurations may require additional time. -
Q: Can the system be integrated with existing plant control?
A: Yes, the PLC controller supports Modbus RTU communication as an option, allowing integration with SCADA or DCS systems. -
Q: What warranty do you offer?
A: We provide a standard 12-month warranty from the date of shipment, covering manufacturing defects. Extended warranty plans are negotiable. -
Q: Are there any specific power requirements besides 220V?
A: The standard model is designed for 220V single-phase or three-phase. For other voltages (e.g., 380V, 400V, 480V), we can adjust the heating elements and controls – please contact us with your local power specifications.
Conclusion
With robust engineering, automatic operation, and IP65 protection, the 220V 15kW Skid-Mounted Evaporator from Qingdao Conqinphi is a smart investment for industries seeking efficient liquid reduction. Backed by our large-scale production capabilities, global shipping experience, and a team of 200+ professionals, we guarantee reliable performance and responsive support. Contact us today to discuss your specific application and request a quotation or technical proposal.
