As a leading manufacturer based in Qingdao, China, Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly introduces our Skid-Mounted Evaporator — a highly efficient, compact, and fully integrated solution designed for industrial wastewater concentration and volume reduction. Established in 2015, our factory spans over 10,000 square meters and employs 201–300 skilled professionals. We have exported products worth US$10 million to US$50 million annually to markets across North America, South America, Europe, Southeast Asia, Africa, and Oceania. This evaporator is not only engineered for performance, but also comes with free installation training for overseas clients and a 24-month warranty, ensuring you receive full support from day one.
The unit is pre-assembled on a rigid skid, allowing quick commissioning and mobility. Whether you are treating high-salinity wastewater, recovering valuable by-products, or reducing disposal costs, this evaporator delivers consistent, reliable operation with minimal maintenance. Below we detail the key features, technical specifications, and the tangible benefits you can expect.
Key Features & Advantages
- Skid-Mounted Design: Factory-assembled on a heavy-duty steel skid, the evaporator requires minimal on-site installation. Simply connect power, feed, and discharge lines, and it is ready to operate.
- High Evaporation Efficiency: Utilizing advanced heat transfer technology, the system achieves evaporation rates of up to 5000 L/h per module, with thermal efficiency exceeding 90% (depending on configuration).
- Energy-Saving Options: Choose from electric heating, steam heating, or thermal oil systems. Optional heat recovery modules can reduce energy consumption by 20%–30%.
- Corrosion-Resistant Materials: All wetted parts are made of 304 or 316L stainless steel, or custom alloys for aggressive chemical streams.
- Automated Control System: PLC-based controls with touchscreen HMI enable automatic start/stop, temperature regulation, level control, and alarm notifications. Remote monitoring is also available.
- Compact Footprint: The entire unit fits within a standard 20ft or 40ft container footprint — perfect for space-constrained sites or temporary installations.
- Easy Maintenance: Modular construction allows quick access to heat exchangers, pumps, and valves. Routine cleaning and inspection can be performed by a single operator.
- Free Installation Training: Our engineers provide hands-on training (remote or on-site) to ensure your team can operate and maintain the evaporator confidently.
- 24-Month Warranty: Coverage includes defects in materials and workmanship, with rapid spare parts delivery from our Qingdao warehouse.
Technical Specifications (Standard Models)
| Parameter | Model SE-500 | Model SE-1500 | Model SE-3000 |
| Evaporation Capacity (L/h) | 500 | 1500 | 3000 |
| Heating Power (kW) | 10–15 | 30–40 | 60–75 |
| Skid Dimensions (L×W×H, m) | 2.5 × 1.8 × 2.0 | 3.5 × 2.2 × 2.5 | 5.0 × 2.4 × 2.8 |
| Weight (kg) | ~1200 | ~2800 | ~4800 |
| Max Operating Temperature (°C) | 120 | 120 | 120 |
| Material (Standard) | 304 SS | 316L SS | 316L SS |
| Control System | PLC + HMI | PLC + HMI | PLC + HMI |
| Warranty | 24 months | 24 months | 24 months |
These specifications are indicative. Custom capacities, voltages (380V/415V/480V, 50Hz/60Hz), and materials are available upon request. The evaporator can handle feed streams with TDS up to 250,000 ppm, including brines, spent caustic, and industrial effluents.
Customer Benefits at a Glance
- Reduced Disposal Costs: Up to 95% volume reduction means less waste to haul or treat downstream.
- Fast Payback: Lower energy consumption and minimal operator intervention lead to quick return on investment.
- Global Compliance: Designed to meet international standards for pressure vessels and electrical safety (CE, ASME, etc., can be arranged).
- Local Support: With our main markets spanning 6 continents, we offer responsive after-sales service via email, video call, or on-site visit.
Trustworthiness backed by numbers: Since 2015, Qingdao Conqinphi has grown into a team of over 200 professionals operating a 10,000+ m² factory. Our annual export value reaches US$10 million to US$50 million, and we have served clients in more than 50 countries. We hold multiple certifications including ISO9001, ISO14000, OHSAS18001, and SA8000, reflecting our commitment to quality, environment, and social responsibility.
Choosing our Skid-Mounted Evaporator means investing in a proven technology backed by a manufacturer that stands behind its product. The free installation training ensures your team gains hands-on experience, and the 24-month warranty gives you peace of mind. We invite you to contact us for a customized solution tailored to your wastewater characteristics and capacity requirements. Let us help you turn your liquid waste into manageable solid residue while saving costs.
Frequently Asked Questions (FAQ)
Q1: What does the free installation training include?
A: The training can be conducted remotely via live video or on-site by one of our engineers (travel expenses are covered by the client; our service is free). Topics cover system setup, operation, routine maintenance, and troubleshooting. We also provide comprehensive manuals and video tutorials.
Q2: Is the 24-month warranty valid for all components?
A: The warranty covers defects in materials and workmanship for the entire unit, including heat exchangers, pumps, valves, and electrical components. Consumable parts like gaskets and filters have a separate 12-month warranty. We will replace or repair faulty parts free of charge within the warranty period.
Q3: Can the evaporator handle high-viscosity or high-salinity liquids?
A: Yes, our standard design can handle TDS up to 250,000 ppm. For viscous or crystalline liquids, we offer options such as scraped-surface heat exchangers or forced circulation to prevent scaling. Please provide your fluid analysis for a tailored recommendation.
Q4: What are the typical delivery times?
A: For standard models (SE-500 to SE-3000), production takes 30–45 days after order confirmation. Custom designs may require 60–90 days. We ship from Qingdao port. Free training can be scheduled before shipment or during commissioning.
Q5: Do you provide spare parts and after-sales support worldwide?
A: Absolutely. We maintain an inventory of commonly used spare parts. For urgent needs, we can ship via express courier within 48 hours. Our technical support team is available via email, WhatsApp, and video calls during business hours (GMT+8).
Q6: What certifications does the evaporator comply with?
A: The unit is built according to domestic standards and can be certified to meet CE (for Europe) or ASME (for USA) upon request at additional cost. Our factory itself is ISO9001, ISO14000, OHSAS18001, and SA8000 certified, ensuring high-quality manufacturing processes.
Q7: Is the skid-mounted evaporator easy to move after installation?
A: Yes, because it is mounted on a steel skid with forklift or crane lifting points, it can be relocated as needed. However, when relocating, you should disconnect and re-pipe the feed and discharge lines. The unit is also suitable for containerized setups for portability.
Q8: Can I get a custom color or specific electrical voltage?
A: Yes, we offer customization of color (RAL code) and electrical ratings (e.g., 380V/415V/480V, 50Hz or 60Hz). Please confirm with our sales team before ordering.
