Compact Skid-Mounted Evaporator 100L/h Capacity 316L Stainless Steel for Chemical Processing
Product Spotlights
Compact skid-mounted design saves space and installation cost. 316L SS ensures corrosion resistance for chemical processing. 100L/h capacity suits pilot and small production. Energy-efficient, modular, and customizable with PLC control. Backed by ISO9001 certified manufacturer with global export experience and strong after-sales support.
US$ 32600 - 875000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Material:
Other, 316L Stainless Steel
Application:
Other, Chemical Processing
Certification:
Other, ISO9001
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
15 days
Related Products
-
220V 15kW Skid-Mounted Evaporator With Automatic Feed System and IP65 EnclosureUS$ 32600 - 875000MOQ: 1 Combo -
Skid-Mounted Evaporator With Free Installation Training and 24-Month Warranty for Overseas ClientsUS$ 32600 - 875000MOQ: 1 Combo
-
≥0.5t/H Skid-mounted Forced Circulation Double-effect MVR Crystallization EvaporatorUS$ 830 - 738000MOQ: 1 Combo
-
Skid-mounted MVR Evaporation Equipment for Mother Liquor Drying SystemUS$ 7480 - 65800MOQ: 1 Combo
-
Skid-mounted MVR Evaporation System Falling Film Water EvaporatorUS$ 3900 - 78400MOQ: 1 Combo
Material
Other, 316L Stainless Steel
Application
Other, Chemical Processing
Certification
Other, ISO9001
Capacity
100 L/h
Mounting Type
Skid-Mounted
Design
Compact, Modular
Voltage
Customizable (e.g., 380V/50Hz)
Working Temperature
Customizable (up to 150°C or higher)
Pressure Rating
Customizable (vacuum to atmospheric)
Origin
Qingdao, China
Qingdao Conqinphi Environmental Technology Group Co., Ltd., a leading manufacturer established in 2015 with a 10,000–30,000 m² factory and annual export value exceeding US$10 million, proudly introduces our Compact Skid-Mounted Evaporator (100L/h Capacity, 316L Stainless Steel). Designed specifically for demanding chemical processing environments, this evaporator combines space-saving skid-mounting with superior corrosion resistance and precise evaporation control. Whether you need to concentrate heat-sensitive solutions or recover solvents, our unit offers reliable, low-maintenance performance backed by ISO9001-certified quality systems.
Key Features & Technical Specifications
- 316L Stainless Steel Construction: All wetted parts are made of 316L SS, ensuring excellent resistance to chlorides, acids, and other corrosive chemicals commonly used in chemical processing.
- Compact Skid-Mounted Design: Pre-assembled on a heavy-duty skid, the unit reduces installation time and footprint. Ideal for retrofits or space-constrained facilities.
- 100 L/h Evaporation Capacity: Perfect for small-to-medium batch production, pilot plants, or R&D applications. Handles feed rates up to 100 liters per hour with consistent concentration.
- Energy-Efficient Operation: Utilizes advanced heat exchange technology (plate or tubular type, customizable) to minimize energy consumption while maintaining high evaporation efficiency.
- Modular & Customizable: Optional accessories such as vacuum pump, condenser, control panel, CIP system, and automatic level control are available per your process requirements.
- Easy Maintenance: Skid layout provides clear access to all components, simplifying inspection, cleaning, and part replacement.
- Wide Application Range: Suitable for concentrating chemicals, recycling solvents, treating wastewater, and producing pharmaceutical intermediates.
| Parameter | Specification |
|---|---|
| Model | CQ-SME-100 (Customizable) |
| Evaporation Capacity | 100 L/h (at standard conditions) |
| Material of Construction | 316L Stainless Steel (wetted parts) |
| Operating Temperature | Up to 150°C (customizable higher) |
| Operating Pressure | Atmospheric / Vacuum (optional) |
| Power Supply | 380V/50Hz (or as requested) |
| Skid Dimensions (approx.) | 1200 x 800 x 1500 mm (customizable) |
| Control System | PLC with HMI (optional) |
Customer Benefits
- Space Savings: The compact skid-mounted layout occupies minimal floor area, making it ideal for laboratories, pilot plants, and facilities with limited space.
- Reduced Installation Costs: Factory pre-assembled and tested units arrive ready to connect, saving you on-site labor and commissioning time.
- Enhanced Safety: 316L SS resists chemical attack, reducing leak risks. Optional vacuum operation lowers boiling points, minimizing thermal degradation and hazards.
- Consistent Quality: Precise temperature and pressure control ensure uniform evaporation, improving product quality and batch reproducibility.
- Low Operating Costs: Energy-efficient heat exchangers and optional heat recovery systems cut utility expenses. Durable construction reduces replacement frequency.
- Flexibility: Easily adaptable to different feed stocks and concentration ratios. Retrofittable with additional modules like distillation columns or crystallizers.
Trust & Expertise
With over 200 skilled employees and a factory spanning 10,000–30,000 m², Qingdao Conqinphi Environmental Technology Group has been delivering reliable evaporation solutions since 2015. Our annual export value of US$10–50 million reflects strong global demand across North America, Europe, Southeast Asia, the Middle East, Africa, and Oceania. We hold multiple certifications including ISO9001, ISO14000, and OHSAS18001, ensuring our products meet stringent quality and environmental standards. Each Compact Skid-Mounted Evaporator undergoes rigorous testing before shipment, and we offer comprehensive after-sales support including online technical assistance, spare parts availability, and optional on-site commissioning. Choose Conqinphi for a partner that combines engineering innovation with manufacturing scale — contact us today to discuss your specific chemical processing needs.
Frequently Asked Questions
-
Q: Can this evaporator handle corrosive chemicals like hydrochloric acid or sodium hydroxide?
A: Yes. The 316L stainless steel construction offers excellent resistance to many acids, alkalis, and chlorides. However, for highly concentrated or extreme chemicals, we recommend consulting our engineers to verify compatibility and optional coatings if needed. -
Q: Does the unit require a concrete foundation for installation?
A: No. The heavy-duty skid is designed to be placed on a level, load-bearing floor. For outdoor or uneven surfaces, a simple steel base plate can be provided. The skid-mounted design eliminates the need for complex civil works. -
Q: What is the typical energy consumption for 100 L/h evaporation?
A: Energy consumption varies based on feed properties and operating temperature. For water-like feeds at atmospheric pressure, approximate steam consumption is 1.1–1.3 kg steam per kg of evaporated water. We can provide a detailed energy balance for your specific process. -
Q: Can I integrate this evaporator with my existing process control system?
A: Yes. Our standard PLC can communicate via Modbus, Profibus, or Ethernet IP. The control panel includes remote start/stop, alarms, and data logging. Custom integration is available upon request. -
Q: What is the lead time for a standard unit?
A: Typical lead time is 30–45 days after order confirmation, depending on customization level. Expedited delivery can be arranged for urgent projects. -
Q: Do you provide after-sales technical support?
A: Absolutely. We offer lifetime remote support via phone, email, and video call. Spare parts are stocked and can be shipped within 72 hours. On-site commissioning and training are also available at an additional cost. -
Q: Can this unit be used for solvent recovery?
A: Yes, when equipped with a condenser and vacuum system, it is well-suited for recovering solvents like ethanol, acetone, or toluene. The 316L material handles many organic solvents safely. -
Q: How often does the evaporator need maintenance?
A: Routine inspection of gaskets, seals, and heat transfer surfaces is recommended every 3–6 months, depending on operating severity. Full maintenance intervals can be customized based on your usage patterns, and we provide a detailed maintenance manual.
