PLC Controlled Skid-Mounted Evaporator 380V 3-Phase 50Hz With Touch Screen Interface
Product Spotlights
PLC-controlled automation with touch screen interface for precise operation; 380V 3-phase 50Hz power; skid-mounted for easy installation; stainless steel construction; high evaporation efficiency; customizable capacity; ISO9001/ISO14000/OHSAS18001 certified manufacturer; global export experience.
US$ 32600 - 875000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Material:
Other, Stainless Steel (SS304/SS316 optional)
Application:
Other, Industrial wastewater
Certification:
Other, ISO9001
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
15 days
Related Products
-
Skid-Mounted Evaporator With CIP Cleaning System 304 Stainless Steel 2000L Batch CapacityUS$ 32600 - 875000MOQ: 1 Combo -
Compact Skid-Mounted Evaporator 100L/h Capacity 316L Stainless Steel for Chemical ProcessingUS$ 32600 - 875000MOQ: 1 Combo
-
220V 15kW Skid-Mounted Evaporator With Automatic Feed System and IP65 EnclosureUS$ 32600 - 875000MOQ: 1 Combo
-
Skid-Mounted Evaporator With Free Installation Training and 24-Month Warranty for Overseas ClientsUS$ 32600 - 875000MOQ: 1 Combo
-
≥0.5t/H Skid-mounted Forced Circulation Double-effect MVR Crystallization EvaporatorUS$ 830 - 738000MOQ: 1 Combo
Material
Other, Stainless Steel (SS304/SS316 optional)
Application
Other, Industrial wastewater
Certification
Other, ISO9001
Warranty
1 Year (extended available)
Power Supply
380V, 3-Phase, 50Hz
Control System
PLC with Touch Screen Interface
Mounting Type
Skid-Mounted
Evaporation Capacity
Customizable (available upon request)
Brand
Conqinphi
Qingdao Conqinphi Environmental Technology Group Co., Ltd. is a leading manufacturer with over 8 years of expertise in environmental equipment. Our PLC Controlled Skid-Mounted Evaporator (380V, 3-Phase, 50Hz, with Touch Screen Interface) is engineered to deliver superior evaporation performance for industrial wastewater treatment, chemical concentration, and brine reduction. Designed as a compact, pre-assembled skid unit, this evaporator offers plug-and-play installation, minimal footprint, and intelligent automation—making it the ideal solution for facilities seeking reliable, energy-efficient water recovery.
Key Features & Technical Advantages
- PLC + Touch Screen Control: User-friendly HMI allows real-time monitoring, parameter adjustment, and fault diagnostics. Operators can easily set evaporation temperature, feed rate, and discharge cycle.
- 380V 3-Phase 50Hz Power: Robust electrical configuration suitable for industrial environments worldwide. Voltage and frequency variations can be customized (e.g., 60Hz or 415V upon request).
- Skid-Mounted Design: All components (evaporator vessel, heat exchanger, pump, control panel, piping) are integrated on a heavy-duty steel skid. Reduces site preparation and installation time by up to 50%.
- High Efficiency Heat Transfer: Utilizes forced circulation or falling film technology (depending on model) to maximize heat transfer coefficient and minimize energy consumption.
- Corrosion-Resistant Construction: Standard material is SS304; SS316, duplex stainless steel, or titanium are available for aggressive chemical streams.
- Automated Safety Systems: Includes over-temperature protection, low-level alarm, pressure relief valve, and emergency stop. Complies with international safety standards.
- Low Maintenance: Self-cleaning design with CIP (Clean-in-Place) ports reduces downtime and manual cleaning requirements.
Technical Specifications (Example Model)
| Parameter | Value |
| Evaporation Capacity | 500 – 10,000 L/h (customizable) |
| Power Consumption | 15 – 200 kW (depending on capacity) |
| Operating Temperature | 60 – 100°C (adjustable) |
| Feed Inlet Pressure | 0.2 – 0.5 MPa |
| Control Voltage | 24V DC (PLC) / 380V AC (main power) |
| Dimensions (L×W×H) | Varies by model (typical 4m×2m×3m) |
| Weight | ~3 – 15 tons |
Benefits for Your Business
- Operational Cost Reduction: Lower energy consumption compared to traditional evaporators; heat recovery options available.
- Minimal Operator Intervention: PLC logic automates start-up, steady-state operation, and shutdown. Touch screen provides clear data visualization.
- Scalable & Flexible: Skid units can be combined in parallel for larger capacity. Suitable for a wide range of feed concentrations (up to 25% solids).
- Environmental Compliance: Reduces wastewater volume by up to 95%, helping meet discharge regulations and lowering disposal costs.
- Rapid Deployment: Fully assembled and tested in our factory before shipping. Only electrical and piping connections needed on site.
Why Choose Conqinphi?
As a manufacturer with a 10,000–30,000 m² factory and a dedicated team of 201–300 professionals, we have delivered hundreds of evaporation systems to clients across North America, South America, Europe, Southeast Asia, the Middle East, Africa, and Oceania. Our annual export value exceeds US$10 million, reflecting strong global trust. We hold multiple certifications including ISO9001, ISO14000, OHSAS18001, HACCP, and SA8000, ensuring that every system meets rigorous quality, environmental, and social responsibility standards.
We understand that every project is unique. Our engineers offer customized design, on-site commissioning, and after-sales support. With a proven track record in industries such as food processing, chemical manufacturing, oil & gas, and pharmaceuticals, we are confident that our PLC Controlled Skid-Mounted Evaporator will exceed your expectations.
Contact us today for a detailed proposal and technical drawing tailored to your specific evaporation needs. Let Conqinphi be your trusted partner in sustainable water management.
Frequently Asked Questions (FAQ)
-
Q: What types of liquids can this evaporator handle?
A: It is designed for aqueous solutions with low to moderate fouling tendency, such as industrial wastewater, brine, cooling tower blowdown, food processing effluent, and chemical by-products. For highly corrosive or viscous fluids, we offer material and design modifications. -
Q: Can I use this evaporator with a 60Hz power supply?
A: Yes, we can customize the electrical components (motors, pumps, PLC) for 60Hz or other voltages. Please specify your local power conditions. -
Q: Is the touch screen interface available in multiple languages?
A: Yes, the HMI software supports English, Chinese, and other languages upon request. The interface is intuitive and requires minimal training. -
Q: What is the typical delivery time?
A: Standard models can be shipped within 30–45 days after order confirmation. Customized units may require 60–90 days depending on complexity. -
Q: Do you provide installation and commissioning support?
A: Yes, we offer on-site supervision or remote guidance. Our service team can also train your operators. -
Q: How do I determine the right capacity for my application?
A: We need information about feed flow rate, desired concentration, and heat source availability. Our engineering team can perform a calculation and recommend the optimal model. -
Q: What warranties are included?
A: Standard warranty is 1 year against manufacturing defects. Extended warranties and spare parts packages are available. -
Q: Can this evaporator be integrated with an existing wastewater treatment system?
A: Absolutely. The skid-mounted design includes inlet/outlet flanges that can be easily connected to your existing piping and control system.
