LHS Vertical Gas Oil Steam Boiler
Introducing the LHS vertical gas oil steam boiler, a pinnacle of innovation and efficiency meticulously crafted by Yangzhou Zhongrui Boiler Co., Ltd. This high-performance steam generator embodies cutting-edge design principles coupled with an abundance of hands-on expertise.
Designed with a sophisticated vertical configuration, this boiler boasts an optimal internal layout that promises superior heat transfer, exceptional thermal efficiency, and an enduring lifespan. Fully assembled for your convenience, it ensures rapid on-site setup and initiation. Simply connect water, fuel, and electricity-no additional civil work or specialized installation needed.
Every LHS vertical gas oil steam boiler is subjected to rigorous testing and comprehensive commissioning before it departs our facility, ensuring unparalleled performance and safety. The boiler's core components include a masterfully engineered boiler body, a premium burner suited for gas oil, an intuitive control system, and state-of-the-art instrumentation and pumps, along with essential accessories.
The LHS series excels with its efficient gas oil combustion, minimal emissions, user-friendly operation, and abundant steam output, making it the preferred choice across diverse industries including boutique manufacturing, catering, and laundry services.
Main Technical Parameters
Boiler Model: LHS Series
Structure Type: Vertical
Rated Capacity: Varies (customizable to meet your specific requirements)
Rated Pressure: Customizable (to align with diverse operational conditions)
Rated Temperature: Customizable (harmonized with rated pressure and application needs)
Applicable Fuels: Gas oil
Product Parameters
| VERTICAL FUEL(GAS) ATMOSPHERIC STEAM BOILER | ||||||||
| Model | Rated Capacity (t/h) | Rated Pressure (Mpa) | Rated Temperature (ºC) | Maximum Transport Weight of Boiler (t) | Maximum Transport Size of Boiler (mm) | Diesel Oil Consumption (Kg/h) | Natural Gas Consumption (m³/h) | LPG Consumption (Kg/h) |
| LHS0.05 | 0.05 | 0.4 | 151 | 0.37 | 700*650*1700 | 8.2 | 10.2 | 6.45 |
| LHS0.1 | 0.1 | 0.4 | 151 | 0.59 | 800*750*2000 | 11.3 | 13.6 | 13 |
| LHS0.2 | 0.2 | 0.4 - 0.7 | 151 - 170 | 0.68 | 900*850*2000 | 15.6 | 18.7 | 19.4 |
| LHS0.3 | 0.3 | 0.4 - 0.7 | 151 - 170 | 0.83 | 1000*950*2000 | 22.5 | 26.8 | 25.6 |
| LHS0.5 | 0.5 | 0.4 - 0.7 | 151 - 170 | 1.07 | 1100*1050*2000 | 32.5 | 36.8 | 32 |
| LHS0.7 | 0.7 | 0.4 - 0.7 | 151 - 170 | 1.45 | 1200*1150*2200 | 40.6 | 48.5 | 50 |
| LHS1 | 1 | 0.4 - 0.7 | 151 - 170 | 1.78 | 1300*1250*2450 | 45.9 | 65.3 | 65 |
| LHS1.5 | 1.5 | 0.4 - 0.7 | 151 - 170 | 1.9 | 1780*1600*3200 | 78.4 | 102.1 | 97 |
| LHS2 | 2 | 0.4 - 0.7 | 151 - 170 | 5.2 | 2000*2000*4000 | 91.8 | 130.6 | 130 |
