The scraper self-cleaning filter is a highly efficient and practical filtration device that plays an important role in many industrial fields. It is mainly composed of a filter cylinder, filter elements, a scraper device, a driving device, and a control system. Its working principle is based on the mechanism of physical interception and automatic cleaning to achieve a continuous and stable filtration process.
During the filtration stage, the fluid to be filtered enters the interior of the filter cylinder from the inlet of the filter. At this time, under the action of pressure, the fluid flows towards the filter elements. Filter elements usually have specific pore sizes or pore structures. Just like a precision filter uses a filter medium to intercept impurities, the filter elements of the scraper self-cleaning filter will intercept impurities such as solid particles, suspended solids, and colloidal particles in the fluid on their surfaces. For example, in chemical production, there may be various fine catalyst particles, reaction by-products and other impurities in the fluid. These impurities will be blocked by the filter elements, while the clean fluid passes through the filter elements and flows out from the outlet of the filter, thus realizing the purification of the fluid.
As the filtration process continues, the impurities intercepted on the surface of the filter elements will continue to accumulate, which will cause the filtration resistance to gradually increase. Just like in a common precision filter during filtration, the accumulation of impurities causes the pressure difference between the inlet and outlet to rise. The scraper self-cleaning filter will also have a similar situation, manifested as an increase in the pressure difference between the inlet and outlet. When the pressure difference reaches the preset value, it means that the impurities on the surface of the filter elements have accumulated to a certain extent, and a cleaning operation is required to restore its filtration performance.
When cleaning is required, the control system will issue an instruction, and the driving device starts to work. The driving device drives the scraper device to rotate, and the blades on the scraper device will be in close contact with the surface of the filter elements. As the scraper rotates, the blades will scrape off the impurities accumulated on the surface of the filter elements. These scraped-off impurities will fall into the dirt collection chamber at the bottom of the filter under the flushing action of the fluid. This process is similar to replacing the filter bag in a bag-type precision filter to resume operation, except that the scraper self-cleaning filter achieves self-cleaning by automatically scraping off the impurities.
After the impurities are scraped into the dirt collection chamber, there is usually a sewage discharge process. By opening the sewage valve, the fluid containing impurities in the dirt collection chamber is discharged outside the filter, thus completing a cleaning cycle. After that, the filter can re-enter the normal filtration stage and continue to purify the fluid.
The working process of the scraper self-cleaning filter is affected by various factors. Filtration accuracy is an important factor, which determines the minimum particle size that the filter can intercept. Different industrial application scenarios have different requirements for filtration accuracy. The flow rate also has an impact on the filtration effect. If the flow rate is too high, it may cause some impurities to not be effectively intercepted, thus reducing the filtration efficiency. Temperature and pressure also need to be controlled within an appropriate range, because different filter elements have their specific working temperature and pressure requirements. Exceeding the range may affect the performance and service life of the filter elements. The properties of the fluid, such as viscosity and chemical composition, also have an effect on the filtration process. For example, a high-viscosity fluid may increase the filtration resistance, and certain chemical components may cause corrosion to the filter elements.
To ensure the long-term and stable operation of the scraper self-cleaning filter, regular maintenance and upkeep are essential. It is necessary to regularly check the wear of the scraper device and replace the severely worn blades in time to ensure the effect of scraping off impurities. The filter elements need to be checked and cleaned. If it is found that the filter elements are damaged or severely blocked and cannot be restored through self-cleaning, they should be replaced in time. The control system and the driving device also need to be checked and debugged to ensure their normal operation and guarantee the normal operation of the entire filter.
