I. Product Overview
Compact, lightweight, aesthetically robust and easy to carry and assemble, the wind vane features a well-designed shape for accurate positioning of natural atmospheric wind direction. Constructed primarily from high-quality polymer carbon fiber, it offers excellent anti-corrosion and anti-erosion properties, ensuring long-term rust-free operation. Coupled with an internal smooth bearing system, it guarantees high precision in data acquisition.
II. Technical Specifications
Item | Technical Specifications |
Threshold Wind Speed | 0.5 m/s |
Measuring Range | 0~360° |
Measuring Accuracy | ±3° |
Resolution | 2.8125° |
Weight | 0.38 kg |
Wind Resistance | > 80 m/s |
Operating Environment | Temperature: -40~+55°C, Humidity: 0~100% RH |
Power Supply | DC 5V or DC 12V (optional) |
Output | 7-bit Gray code signal (with transmitter, can output 4-20mA, RS485, etc.) |
III. Features
· Compact and lightweight, extremely convenient for field transportation and installation; waterproof and shock-resistant structure enables all-weather operation in the field.
· High detection accuracy; the system adopts low-power, eco-friendly design and digital processing technology.
· Wide measuring range and excellent stability.
· Good linearity in data display, long signal transmission distance, and strong resistance to external interference.
IV. Applications
This sensor can measure the outdoor wind direction, covering a full range of 0-360 degrees relative to true north. It offers an excellent cost-performance ratio and is widely used in environmental protection, meteorology, agriculture, forestry, water conservancy, construction, scientific research, and education.
