Product Description:
Overview:
The FIP C150-200 Graphite/Platinum Conductivity Sensor provides highly accurate conductivity measurement for a wide range of applications, including water treatment, agricultural systems, and industrial processes. Designed with either graphite or platinum electrodes, this sensor offers durability and precision, making it suitable for both laboratory and field applications. With 0.1-10 cell constants and a built-in Pt100 temperature sensor for automatic temperature compensation (ATC), the FIP C150-200 ensures precise, real-time conductivity readings.
Key Features:
Graphite or Platinum Electrodes: Choose between graphite for general applications or platinum for high-precision measurements in more demanding environments.
Wide Cell Constant Range: With 0.1-10 cell constants, the sensor can be adapted to various conductivity ranges, making it suitable for a wide range of water types and industrial applications.
Automatic Temperature Compensation (ATC): The built-in Pt100 temperature sensor ensures accurate conductivity measurements by compensating for temperature fluctuations.
Corrosion-Resistant: The durable epoxy resin body and graphite/platinum electrodes ensure long-lasting operation in harsh environments.
IP68 Protection: With an IP68 rating, the sensor is dust-tight and can withstand submersion in water, making it ideal for outdoor and industrial use.
ISO 9001 & CE Certified: The FIP C150-200 meets international quality standards, ensuring reliability and high-performance in critical applications.
Applications:
Water treatment plants
Agricultural irrigation systems
Wastewater treatment
Food & beverage industry
Industrial cooling systems
Chemical processing
Why Choose the FIP C150-200 Sensor?
The FIP C150-200 sensor is engineered for high-precision conductivity measurement, with options for both graphite and platinum electrodes. Whether for agriculture, water treatment, or industrial applications, the FIP C150-200 offers exceptional performance, reliable data, and long-term durability. Its flexibility in cell constants and temperature compensation ensures accurate readings, making it a versatile solution for diverse conductivity monitoring needs.
Order Now: Upgrade your conductivity monitoring with the FIP C150-200 sensor today.
FAQ:
What is the output of the FIP C150-200?
The FIP C150-200 provides a standard 4-20mA output, making it compatible with most industrial controllers.
Can I use the FIP C150-200 for both water treatment and agriculture?
Yes, the FIP C150-200 is suitable for a wide range of applications, including water treatment, agricultural irrigation, and industrial systems.
What electrode materials are available for the FIP C150-200?
The sensor is available with either graphite or platinum electrodes, depending on the precision and application requirements.
How does Automatic Temperature Compensation work?
The built-in Pt100 temperature sensor automatically adjusts the conductivity readings for temperature variations, ensuring accuracy.
What are the installation options for the sensor?
The FIP C150-200 can be installed in-line or submerged, with various connection options like M12 or NPT threads for easy integration.
What are the key certifications for the FIP C150-200?
The sensor is ISO 9001, CE, and RoHS certified, ensuring it meets international quality and environmental standards.
Can the sensor be used outdoors?
Yes, the FIP C150-200 is IP68 rated, meaning it is dust-tight and can withstand immersion in water, making it suitable for outdoor and harsh industrial environments.
What temperature range can the sensor handle?
The sensor operates in a temperature range of 0°C to 70°C, making it suitable for a variety of environmental conditions.
