Product Overview:
The FIP C100-300 Stainless Steel Conductivity Sensor is designed for highly accurate conductivity measurements, widely used in agriculture, water treatment, and industrial applications. Equipped with Automatic Temperature Compensation (ATC) and a wide range of conductivity cell constants (0.01-10), this sensor ensures reliable performance under varying conditions, with durable stainless steel construction for long-lasting service life.
Key Features:
Stainless Steel Construction: The FIP C100-300 uses stainless steel electrodes and housing (C300 model) for superior resistance to corrosion, ensuring the sensor performs reliably in harsh environments.
Automatic Temperature Compensation (ATC): Ensures accurate conductivity readings by adjusting for temperature fluctuations, making it ideal for environments with variable conditions.
Flexible Cell Constants: Available in multiple cell constants (0.01-10), allowing you to select the best option based on your specific application.
Wide Range of Applications: Perfect for agricultural water treatment, industrial cooling systems, wastewater treatment, and more. Suitable for both clean and polluted water systems.
Durable and Reliable: With an IP68 protection rating, the FIP C100-300 can withstand exposure to water and dust, ensuring longevity and minimal maintenance in harsh environments.
Temperature and Pressure Resistance: The sensor operates at a temperature range of up to 80°C (C100) and 120°C (C300) and can handle up to 7 bar of pressure, making it ideal for a variety of industrial applications.
Applications:
Agricultural water systems and fertigation control
Water and wastewater treatment plants
Industrial cooling and process water monitoring
Food industry and beverage production
Ultra-pure water applications
Why Choose the FIP C100-300 Stainless Steel Conductivity Sensor?
The FIP C100-300 sensor provides exceptional accuracy and durability for measuring conductivity across a wide range of applications. Its robust stainless steel construction ensures long-term operation, and the flexibility of cell constants allows you to select the best configuration for your needs. Whether you're in agriculture, water treatment, or industrial processing, this sensor offers unmatched reliability and performance.
Order Now: Equip your system with the FIP C100-300 Stainless Steel Conductivity Sensor today for accurate and reliable conductivity measurements.
FAQ:
What is the maximum temperature the sensor can withstand?
The FIP C100 can withstand temperatures up to 80°C (176°F), while the C300 model can handle up to 120°C (248°F).
How does Automatic Temperature Compensation (ATC) work?
The sensor uses ATC to automatically adjust conductivity readings based on temperature variations, ensuring precise measurements even in fluctuating conditions.
What types of applications is the FIP C100-300 suitable for?
The sensor is ideal for agricultural water systems, wastewater treatment, industrial cooling, and even ultra-pure water applications.
What is the output of the FIP C100-300 sensor?
The sensor provides a 4-20mA output, making it compatible with most industrial controllers and data acquisition systems.
Can I use this sensor in outdoor environments?
Yes, the FIP C100-300 has an IP68 protection rating, meaning it is fully protected against dust and can withstand immersion in water, making it perfect for harsh outdoor conditions.
How do I choose the correct cell constant for my application?
The sensor offers multiple cell constants (0.01-10), allowing you to select the best option based on your conductivity measurement needs. Higher constants are typically used for more conductive liquids, while lower constants are used for ultrapure or low-conductivity applications.
What materials are used for the sensor construction?
The FIP C100 series features a durable PP (polypropylene) body, while the FIP C300 series uses stainless steel for greater resistance to harsh chemicals and extreme conditions.
Can I integrate this sensor with existing systems?
Yes, the 4-20mA output makes it easy to integrate the FIP C100-300 into existing control and monitoring systems for seamless operation.
