Bently Nevada 3500/15 106M1079-01 Universal AC Power Supply

Functional Description

106M1079-01 is a Universal AC Power Supply manufactured and designed by Bently Nevada. It is a part of the 3500/15 System. They are half-height modules that must be installed in specific slots on the rack's left side. The rack can house one or two power supplies that can be AC or DC in any combination. A full rack can be powered by either supply. When two power supplies are installed in a rack, the one in the lower slot serves as the primary power supply, and the one in the upper slot serves as the backup power supply. If installed, the secondary power supply serves as a backup for the primary one.

Features

• As long as a second power supply is installed, removing or inserting either power supply module has no effect on the operation of the rack.

• The DC Power Supplies accept a wide range of input voltages and converts them to voltages that other 3500 modules can accept.

• The Legacy AC Power Supply, High Voltage AC PIM, and Low Voltage AC PIM are incompatible with the Universal AC Power Supply and PIM (Power Input Module).

• The Legacy High Voltage and Low Voltage DC Power Supplies and PIMs are incompatible with the Legacy 3500 High Voltage and Low Voltage DC Power Supplies and PIMs.

Voltage OptionsDescription:

• This option uses the universal AC Power Supply and universal AC Power Input Module (PIM).

Input Voltage:

• 110 to 220 Vac nominal Non-hazardous areas:85 to 264 Vac rms

• Hazardous areas: 85 to 250 Vac rms

• 120 to 373 Vac pk

• The universal AC Power Supply and Power Input Module are not compatible with the legacy High Voltage AC or Low Voltage AC units.

Input Frequency:

• 47 to 63 Hz

Input Characteristics: This power supply module usually supports a wide range of input voltages and can accept either AC or DC input. The common AC input voltage range may be between 85V and 265VAC, and the DC input voltage range may be between 108V and 145VDC. The operating frequency is generally between 47 and 63Hz to adapt to different industrial power supply environments.

Output Characteristics: It can output a stable voltage required by each module of the 3500 system. For example, it provides reliable power supply for the monitoring modules and interface modules within the rack. The stability of the output voltage is very important for ensuring that the system can accurately monitor the status of the equipment.

Redundant Configuration: In some applications with high requirements for reliability, the 3500 system can install two 3500/15 power supply modules to achieve redundant configuration. In this case, the main power supply is installed in the lower slot, and the redundant power supply is installed in the upper slot. When the main power supply fails, the redundant power supply can automatically take over the power supply to ensure that the system continues to operate normally, improving the reliability and fault tolerance of the system.

Status Indication: It is usually equipped with status indicator lights to display the working status of the power supply module. For example, there may be indicator lights to show whether the power supply is normally energized and whether the output voltage is within the normal range. This facilitates operators to quickly determine the operating status of the power supply module and conduct fault diagnosis and maintenance.

Certification and Standards: The products of Bently Nevada usually follow strict industrial standards and specifications. The 3500/15 may comply with relevant electrical safety standards, electromagnetic compatibility (EMC) standards, etc., to ensure reliable operation in industrial environments and compatibility with other devices.

Application Fields: It is widely applied in industrial fields such as petroleum, chemical, power, and metallurgy. It provides stable power support for key equipment (such as steam turbines, compressors, pumps, etc.) equipped with the 3500 series mechanical protection and monitoring system, ensuring the safe and reliable operation and status monitoring of the equipment.
