ZAY7045V Variable Speed Milling and Drilling Machine With CE Standard
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ZAY7045FG Gear Head Drilling and Milling Machine With Metal WorkingNegotiableMOQ: 1 -
Anhui Mini Manual Milling and Drilling Machine ZAY7032G for PlasticNegotiableMOQ: 1
-
ZAY7032V Variable Speed Drilling Milling Machine for Metal WorkingNegotiableMOQ: 1
-
ZAY7045V Variable Speed Mini Milling and Drilling Machine for SaleNegotiableMOQ: 1
-
ZAY7025V Mini Milling and Drilling Machine for Metal WorkingNegotiableMOQ: 1
Model: ZAY7045V milling and drilling machine
Model | ZAY7032V | ZAY7040V | ZAY7045V | ||
Max drilling capacity | 32mm | 40mm | 45mm | ||
Max Face mill capacity | Φ63mm | Φ80mm | Φ80mm | ||
Max End mill capacity | Φ20mm | Φ32mm | Φ32mm | ||
Max distance from spindle nose to table | 400mm | 450mm | |||
Min distance from spindle axis to column | 260mm | ||||
Spindle travel | 130mm | ||||
Spindle taper | MT3 , MT4 or R8 | ||||
Range of spindle speed | 100-530rpm 530-2600rpm | ||||
Swivel angle of headstock (perpendicular) | ±90° | ||||
Table size | 800×240mm | ||||
Forward and backward travel of table | 175mm | ||||
Left and right travel of table | 500mm | ||||
Motor Power | 1.1KW/1.1KW/1.5KW | ||||
Net/Gross weight | 300kgs/ 350kgs | ||||
Packing size | 770×880×1160mm | ||||
Loading amount/20" container | 36pcs | ||||
