ZAY7045M Universal Milling Machine Price With Rotary Worktable

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Business Type:

Manufacturer

Year Established:

2018

Factory Size:

Below 1,000 square meters

Jingjiang Fuji Technology Co., Ltd.

4Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

1. Drill chuck 1-13mm/B16; 2. Draw bar; 3. Allen wrenchs; 4. Wedge; 5.Tie rod

1.Steel stand and chip tray ; 2. Halogen lamp; 3.Coolant system;

4. 58pcs clamping kits; 5. Face milling cutter diameter 63mm; 6.Milling chuck(8pcs/set); 7.DRO(2-axis or 3-axis)(for FG and FG-1 serials) ;

8.H/V precision rotary table HV-150mm

9.Table power feed X axis (Except for belt driven type); 10. Double speed motor

Specification	ZAY7032FG	ZAY7040FG	ZAY7045FG	ZAY7045M
Drilling capacity	Φ32mm	Φ40mm	Φ45mm	Φ45mm
Face milling capacity	Φ63mm	Φ80mm	Φ80mm	Φ80mm
End milling capacity	Φ20mm	Φ32mm	Φ32mm	Φ32mm
Distance from spindle nose to table	450mm	450mm	450mm	420mm
Min.distance from spindle axis to column	260mm
Spindle travel	130mm
Spindle taper	MT3 or R8	MT4 or R8
Step of spindle speed	6 steps
Range of spindle speed 50Hz	80-1250 r.p.m
60Hz	95-1500 r.p.m
Swivel angle of headstock (vertical)	±90°
Table size	800×240mm
Forward and backward travel of table	175mm
Left and right travel of table	500mm
Motor Power	1.5kw
N.W/G.W	320/370kgs	323/373kgs			325/375kgs
Packing size	770×880×1160mm
