QK1327 High Precision Heavy Cutting CNC Pipe Threading Lathe Machine

Main Feature

High rigidity casting bed

High precision spindle bearing

Bed guideways industively hardened

Specification	QK1327
Max.swing over bed	Ф800mm
Max.swing over carriage	Ф480mm
Max. cutting length	1500mm 3000mm 4000mm 5000mm
Rail width	600/755
Spindle bore	Ф280mm
Chuck size	630mm
Range of spindle speed	(L):20-100rpm(H):100-300rpm
X-axis travel	450/550mm
Z-axis travel	1250mm
X/Z rapid speed	4000mm/min
Electronic turret	4 -station
Max.section of tool	280x280mm
Stroke of tailstock sleeve	250mm
Diameter/Hole of tailstock sleeve	Ф100mm/MT6
Main motor power	15kw
Overall dimensions L x W x H	4600x2060/2100x2100mm
Packing size L x W x H	4800x2260/2300x2300mm
Net weight	7000/9000kgs
Gross weight	8000/10000kgs

Standard Accessories:
1. Cooling system
2. Auto-lubricating system
3. Work lamp
4. GSK-980TDc controller with feeding servo motor
5. 4-Position electrical tool post
6. Unitary iron casting machine stand
7. Manual 3-jaw chuck /2 pcs

Optional Accessories:
1. GSK218M controller

2. Simens 808D controller

3. Simens 808D Advance controller

4. Fanuc Oi TF controller
5. 6/8-Position electrical tool post

Machine pics

GSK980TDC controller

Siemens 808D controller

Fanuc Oi TF controller
