Name: MPV300 Mill Lathe Combo Machine in Sale From China.
SKU: 171485183

ALL CATEGORIES

MPV300 Mill Lathe Combo Machine in Sale From China.

Send Inquiry to This Supplier

Mr. Jack Xu

Sales Manager

4Yrs

Jingjiang Fuji Technology Co., Ltd.

Shanghai, China

* Message

0/5000

* Email

Get quotes from multiple Verified Suppliers simultaneously.

Specification	MPV300
Distance between centers	700mm
Swing over bed	300mm
Spindle taper	MT5
Width of bed	182mm
Spindle bore	38mm
Range of spindle speeds（variable speed）	80-2000rpm
Range of cross feed	0.01 -0.10mm /r
Range of longitudinal feed	0.085-0.832mm/rev
Range of inch threads	8-56T.P.I
Range of metric threads	0.2 -3.5mm
Top slide travel	70mm
Cross slide travel	160mm
Tailstock quill travel	70mm
Taper of tailstock quill	MT3
Main motor	1.5kw
Drilling and milling head	BF20
Spindle taper	MT3
Spindle travel	52mm
Range of spindle speeds（variable speed）	50-2250rpm
Max.distance from spindle nose to table	380mm
Max.distance from spindle to columm	185mm
Motor power	750w
Packing size（for machine）	1450 × 770 × 1050mm
Packing size（for stand）	780x410x600mm
N.W	390kgs
