3000 mm Length CS6250C Heavy Duty Manual Engine Lathe Machine for Metal Cutting
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3m China Heavy Duty Horizontal Lathe Machine With CENegotiableMOQ: 1 -
High Precision Parallel Lathe Engine Bench Manual Lathe Machine C6246 With CE StandardNegotiableMOQ: 1
-
Stock Sale CJM320A Bench Lathe Machine for HobbyNegotiableMOQ: 1
-
DIY0820 Mini Metal Lathe Machine for Hobby UsersNegotiableMOQ: 1
-
AT125 Combined Mini Metal Lathe Machine for Household UseNegotiableMOQ: 1
Product Description
CS6250C horizontal heavy duty metal engine lathe machine with CE
Perform internal and external turning, taper turning, end facing, and other rotary parts turning;
Threading Inch, Metric, Module and D.P.;
Perform drilling, boring and groove broaching;
Respectively with through-hole spindle bore, that can hold bar stocks in larger diameters;
Both Inch and Metric system are used on these series lathes, it's easy for people from different measuring systems countries;
There are hand brake and foot brake for users to choose;
Power supply of different voltages (220V/380V/420V) and different frequencies (50Hz,60Hz) are available.
Machine Specification
Specification |
CS6250C |
Max. swing over bed |
Φ500mm |
Max. swing in gap |
Φ710mm |
Max. swing over slide |
Φ300mm |
Max. workpiece length |
1000/1500mm/2000/3000mm |
Spindle bore |
Φ105mm |
Type of spindle |
ISO 702/II NO.8 com-lock type |
Spindle speed |
12 steps |
36-1600rpm |
|
Spindle motor |
7.5kw |
Diameter of quill |
Φ90mm |
Max. travel of quill |
150mm |
Taper of quill |
MT5 |
Tool O.D. size |
25×25mm |
Max. X travel |
145mm |
Max. Z travel |
320mm |
X feed range |
65 kinds 0.063-2.52mm/r |
Z feed range |
65 kinds 0.027-1.07mm/r |
Metric threads |
22 kinds 1-14mm |
Inch threads |
25 kinds 28-2t.p.i |
Module threads |
18 kinds 0.5-7πmm |
Diametric pitch |
24 kinds 56-4t.p.i.π |
Cooling pump |
60w |
Length |
2632/3132mm |
3632/4632mm |
|
Width |
975mm |
Height |
1270mm/1450mm |
N.W/G.W |
2100/2300kgs/2200/2400kgs |
2500/2900kgs/2600/3000kgs |
Detailed Images
