Q1335 (360mm Big Spindle Bore) Pipe Threading Lathe Machine With CE Protection
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CD6240C 80mm Spindle Bore Manual Engine Lathe Machine for SellNegotiableMOQ: 1 -
CW61125Q Turning Machine 3m China Heavy Duty Horizontal Manual Lathe Machine With CENegotiableMOQ: 1
-
MP800 Mini Metal Lathe for Hobby UsersNegotiableMOQ: 1
-
C6241 Precision Hard Rigid Gap Bed Metal Lathe Machine Price for SaleNegotiableMOQ: 1
-
Stock Sale C6246 High Precision Horizontal Metal Manual Lathe MachineNegotiableMOQ: 1
Pipe Threading Machine Q1335manufactured by WMT
1.Big spindle bore:280mm
2.Double Chuck
3.High precision lathe
4.Casting Iron bed
（Item） |
（Unit） |
Q1335 |
Q1343 |
Q1353 |
||
Max dia.swing over bed |
mm |
1000 |
1200 |
|||
Max dia.swing over cross slide |
mm |
610 |
810 |
|||
Max.length of work-piece |
mm |
1500 |
||||
Width of bed |
mm |
755 |
||||
Spindle bore |
mm |
360 |
440 |
540 |
||
Power of spindle motor |
Kw |
22 |
||||
Spindle speed |
r/min |
6-200 VF2 steps |
5-180 VF2 steps |
5-180 VF2 steps |
||
Z axis feed grade/range |
mm/r |
32/0.1-1.5 |
||||
X axis feed grade/range |
mm/r |
32/0.05-0.75 |
||||
Carriage rapid traverse speed |
mm/min |
3740 |
||||
Cross slide rapid traverse speed |
mm/min |
1870 |
||||
Metric thread grade/range |
mm |
23/1-15 |
||||
Inch thread grade/range |
T.P.I |
22/28-2 |
||||
Traverse of cross slide |
mm |
520 |
||||
Max. Traverse of turret |
mm |
300 |
||||
Tailstock quill travel |
mm |
300 |
||||
Tailstock quill Dia./taper |
mm |
Φ140/莫氏6号（MT6#） |
||||
Chuck |
Φ850 4-jaw eletric |
Φ1000 4-jaw eletric |
||||
Overall dimensions(L*W*H) |
mm |
5000×2100×1680 |
5000×2100×1680 |
5000×2100×1700 |
||
Net weight |
T |
12.8 |
13 |
15 |
||
