CNC lathe machine CK5116 metal cutting CNC vertical lathe machine with CE

Name: CNC lathe machine CK5116 metal cutting CNC vertical lathe machine with CE
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

CNC Vertical Lathe Machine CK5116 Main Features:

1. Vertical CNC lathe machine with single column;

2. Rigid column and stable;

3. DRO is optional;

4. Precise cutting for heavy metal parts.

Specification	CK5116E(SVT160F)
Table dia.	1400mm
Max. turning dia.	1600mm
Max. workpiece height	1000/1200/1400/1600mm
Max. workpiece weight	5(8)t
Table speed step	16
Table rotation speed range	5-160(6.3-200)r/min
Horizontal travel of toolpost (X-axis)	915mm
Vertical travel of toolpost (Z-axis)	800/1000mm
Crossam ram travel	850mm
Tool bar section size(Lx W)	30x40mm
Main motor power	30kw
N.W	12.6/13.3/14/14.6t
Overall size(LXWXH)	2662x2800x3350/3550/3750/3950mm
Tool bar section size(Lx W)	30x40mm
Main motor power	30kw
Feeding motor power	1.3/1.8kw
N.W	12.7t
Overall size(LXWXH)	2662x2800x3550mm

Detailed Images

Company Profile

FAQ

Q1: How is the warranty?

A1: Warranty time is 13 months after BL date.

Q2:Can we visit your factory before order?

A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3:Do you have a stock?

A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4:What’s the MOQ?

A4:One set only.

Q5:How about your quality?

A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6:Do you have professional engineers?

A6:Yes.we have professional engineers and designers. We can provide OEM services.

Q7:Can you provide customized machines?

A7:Yes, we can design and manufacture according to your specific requirements.
