QK1327 280mm Spindle Bore Dia. Pipe Threading Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
200mm Spindle Bore Dia. QK1319 Pipe Threading Machine
-
Desktop Cnc Lathe CK6150 Mini Cnc Lathe for Education for Threads Making
-
CK6432 750mmcheap Cnc Lathe Machine With CE for Metal Working
-
CK42T 3-Axis Turning Center Cnc Lathe
-
SK50P 500mm Cnc Lathe Machine for Sale
-
Extra Large Slant Bed Cnc Lathe CK60T Slant Bed CNC Lathe Machine Heavy Duty Slant Bed Cnc Lathe
Product Description
Machine pics
GSK980TDC controller
Siemens 808D controller
Fanuc Oi TF controller
Technology Data
Main Feature
High rigidity casting bed
High precision spindle bearing
Bed guideways industively hardened
Specification | QK1327 |
Max.swing over bed | Ф800mm |
Max.swing over carriage | Ф480mm |
Max. cutting length | 1500mm |
Rail width | 600/755 |
Spindle bore | Ф280mm |
Chuck size | 630mm |
Range of spindle speed | (L):20-100rpm(H):100-300rpm |
X-axis travel | 450/550mm |
Z-axis travel | 1250mm |
X/Z rapid speed | 4000mm/min |
Electronic turret | 4 -station |
Max.section of tool | 280x280mm |
Stroke of tailstock sleeve | 250mm |
Diameter/Hole of tailstock sleeve | Ф100mm/MT6 |
Main motor power | 15kw |
Overall dimensions L x W x H | 4600x2060/2100x2100mm |
Packing size L x W x H | 4800x2260/2300x2300mm |
Net weight | 7000/9000kgs |
Gross weight | 8000/10000kgs |
Machine Accesories
Standard Accessories:
Cooling system
Auto-lubricating system
Work lamp
GSK-980TDc controller with feeding servo motor
4-Position electrical tool post
Unitary iron casting machine stand
Manual 3-jaw chuck 2 pcs
Optional Accessories:
GSK218M controller
Simens 808D controller
Simens 808D Advance controller
Fanuc Oi TF controller
6/8-Position electrical tool post
Packing & Delivery
Related Products
CNC Lathe CK6136
91.8% Response Rate
Machining center VMC600L
