1kv Isolation (2: 1) Wide Range Input Voltage Regulated Single Dual Output DC-DC Converter Module IC
- 50000 Piece / Pieces per Month
- yantian
- T/T PayPal
- 5 days
You May Like
-
24V Output DC-DC Converter with 8kv Antistatic
-
Potentiometer/Sensor Resistance/Electrical Ruler Signal to 4-20mA/0-5V/0-10V Transmitter Sy (ISO) R-P-O
-
Analog Signal High/Low Signal Selection Controller/Transmitter DIN ISO C3-P2-O1-Sh
-
Fixed Input and Unregulated Dual Voltage Output Isolated DC/DC Converter
-
4-20madifferential Signalacquisition Converter Sy C-A4-P4-O4
-
Current to PWM Signal Converter ISO A6-P1-D1-Q1
Product Details
| Brand Name | Sunyuan technology. | Place of Origin | China | |
| Model Number | DW5-24S05 | Type | DC/DC Converters | |
| Weight | 15 g | Output Power | 1 - 50W | |
| Output Type | Single | Output Current | 1W, 2W | |
| Output Frequency | 1000VDC | Output Voltage | +/-5VDC,+/-12VDC,+/-15VDC,5VDC,12VDC,15VDC,24VDC,E | |
| Input Voltage | 4.5-9V, 9-18V, 18-36V, 36-72V (2:1) |
Product Description
1KV Isolation (2:1) Wide Range Input Voltage Regulated Single Dual Output DC-DC Converter Module IC
Features:
High power density
1500V high galvantic isolation.
No heat sink required.
Regulated single/dual output
Rated 2-5W,6-12W,15-20W output
Industrial standard pin-out
PCB Mounted type dc-dc IC.
Over current/short circuit protection
Applications:
Electric Power System, Power monitoring,voltage conversion.
dual power isolation in digital communication ports of RS232/485, CAN bus.
power supply isolation in intelligent control, security equipments, telecom,etc.
safety isolation in ground loop elimination, medical equipments and instrument.
Isolation & power supply for analogue electric circuit ( Transmitter & sensors).
Power supply isolation & transfer for safety monitoring and smart building system.
Ground loop interference control.
Car electric circuit power isolation & distribution.
Battery power supply, voltage transfer, power distribution.
PLC, DCS,PC isolation regulated power supply.
