2×2 Bypass Mechanical Optical Switch
Description
2x2B Mechanical Optical Switch is used to turn on, turn off and switch optical signal. The 2x2B Mechanical Optical Switch is based on Advanced Optoelectronic Integrated Technology. With the development of optical communication, Optical Switch device is the key to a new generation of all-optical network in near future.
2x2B Mechanical Optical Switch is not affected by the polarization and wavelength. It supports all wavelength at 850nm and 1260nm~1650nm, and It provides high reliability, low insertion loss, fast switching speed and bi-directional performance. They are widely used for multiplex OADM, cross connectors OXC, system testing and protection.
Performance
|
Parameters |
Unit |
2×2 Bypass-MM/SM |
|
Wavelength Range 1 |
nm |
850/1300 |
1260~1630 |
Straight Insertion Loss 2 |
dB |
Typ:0.5 Max:0.8 |
Typ:0.5 Max:1.0 |
Bypass Insertion Loss 2 |
dB |
Typ:0.6 Max:1.2 |
Typ:0.8 Max:1.6 |
Return Loss |
dB |
Typ:-30 |
Typ:-50 |
Crosstalk |
dB |
MM Min.: 45/SM Min.: 55 |
|
PDL |
dB |
≤0.1 |
|
WDL |
dB |
≤0.3 |
|
TDL |
dB |
≤0.25 |
|
Repeatability |
dB |
≤±0.1 |
|
Operating Current |
mA |
150±10% |
|
Power supply |
VDC |
12~48 |
|
Power Consupmption |
mW |
750±10% |
|
EMI Certification |
FCC Class B |
||
Lifetime |
Cycles |
≥107 |
Switch Time 3 |
ms |
≤8 |
Optical Input Power |
mW |
≤500 |
Operating Temperature |
℃ |
-20~+70 |
Storage Temperature |
℃ |
-40~+85 |
Operating Humidity |
%RH |
5~95 |
Storage Humidity |
%RH |
5~95 |
Weight 4 |
g |
510 |
Dimension |
mm |
(L)140.0×(W)95.0×(H)26.0 |
1. Special wavelength would be upon request.
2. Optical parameters excluded connectors.
3. A minimum ≧20ms pulse is recommended for latching type of switch.
4. The product weight excluded optical connectors.
Electric For Switch
Specifications |
Voltage |
Current |
Resistance |
5V latching |
4.5~5.5 |
36~44mA |
125Ω |
5V non-latching |
4.5~5.5 |
26~32mA |
175Ω |
3V latching |
2.7~3.3 |
54~66mA |
50Ω |
3V non-latching |
2.7~3.3 |
39~47mA |
70Ω |
Power Supply
Port |
Indicator |
LED |
Status |
PWR1 |
DC 12-48V |
PWR1/DC 12-48V |
ON/OFF Indicated by LED |
PWR2 |
AC 220V |
PWR2/AC 220V |
ON/OFF Indicated by LED |
