Help Center4CH LAN-WDM BLOCK Specification
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2020
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mini Size Ultra Compact Low Insertion 18 Channel CWDM &DWDM MUX and DEMUXNegotiableMOQ: 1 Piece -
40CH AAWG DWDM ModulesNegotiableMOQ: 1 Piece
-
100GHz DWDM Device (DWDM Filter) TFF MUX DEMUXNegotiableMOQ: 1 Piece
-
2×2 Bypass Mechanical Optical Switch 1x11x21x41x8NegotiableMOQ: 1 Piece
-
Compact 16CH Mini Size CDWDM ModulesNegotiableMOQ: 1 Piece
4CH LAN-WDM BLOCK Specification
Parameter |
Symb |
Min |
Typ |
Max |
Unit |
Channel Number |
4 |
channel |
|||
Channel Wavelength |
lCT0 |
1295.56 |
nm |
||
lCT1 |
1300.05 |
nm |
|||
lCT2 |
1304.58 |
nm |
|||
lCT3 |
1309.14 |
nm |
|||
Pass Band |
Δl |
-1.1 |
+1.1 |
nm |
|
Channel Insertion Loss |
1.0 |
dB |
|||
A.O.I (8) |
7.8 |
8 |
8.2 |
degree |
|
Beam position Error |
0.70 |
0.75 |
0.80 |
mm |
|
Adjacent Channel Isolation |
30 |
dB |
|||
Non-Adjacent Channel Isolation |
35 |
dB |
|||
P D L |
0.25 |
dB |
|||
Return Loss |
40 |
dB |
|||
Directivity |
50 |
dB |
|||
Dimension（LxWxH） |
4.7X3.7X1.0 |
mm |
|||
