Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > Polarization Maintaining Optical Switch(1*2)
Polarization Maintaining Optical Switch(1*2)
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2020
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Polarization Maintaining Coarse Wavelength Division MultiplexerNegotiableMOQ: 1 Piece -
FIBER PATCHCORD & PIGTAIL 12F MPO/MTP-MPO/MTP 10G OM4 3.0 Round Fiber Cable Patch CordNegotiableMOQ: 1 Piece
-
Fiber Oopti Splitter-PLC SplitterNegotiableMOQ: 1 Piece
-
Mini Size Ultra Compact Low Insertion 18 Channel CWDM &DWDM MUX and DEMUXNegotiableMOQ: 1 Piece
-
ABS Pigtail Module CWDM Mux & DemuxNegotiableMOQ: 1 Piece
Specifications:
Parameters |
Unit |
Values |
Center Wavelength |
nm |
1310 and 1550 |
Operating Wavelength Range |
nm |
±40 |
Insertion Loss |
dB |
0.8 |
Extinction Ratio |
dB |
22 |
WDL |
dB |
|
Channel Cross Talk |
dB |
|
Repeatability |
dB |
±0.02 |
Switching Speed |
ms |
|
Return Loss |
dB |
>55 |
Coil Resistance (Pin 1-5 or 6-10) |
ohms |
178 ± 10% |
Durability |
cycles |
>10 million |
Fiber Type |
PM Panda Fiber |
|
Operating Temperature |
℃ |
-40 to +70 |
Storage Temperature |
℃ |
-40 to +85 |
Physical Dimension (LxWxH) |
mm |
TAP A and TAP B |
* Above specifications are for device without connector.
* For devices with connectors, IL will be 0.3dB higher, ER will be 2dB lower and RL will be 5dB lower.
* The PM fiber and the connector key are aligned to the slow axis.
