1u Network Appliance Appliance Based on C236 Chipset

1u Network Appliance Appliance Based on C236 Chipset photo-1
1u Network Appliance Appliance Based on C236 Chipset photo-2
1u Network Appliance Appliance Based on C236 Chipset photo-3
1u Network Appliance Appliance Based on C236 Chipset photo-4
1u Network Appliance Appliance Based on C236 Chipset photo-5
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
5 days
Type Wired

F23611 is an 1U rackmount network security system application hardware appliance, use network application motherboard based on Intel ® C236, supports the 6/7th generation Intel Core processors (codenamed Kaby Lake). The high performance and I/O rich appliance is developed for #networksecurity, #cloudcomputing #datacenters.

Anxin's network appliance based socket LGA1151 supports Intel Kaby Lake CPU & Intel SkyLake CPU.
SeriesModelBase ClockTDPCores / ThreadsGPUMax Clock
XeonE3-1235L v52.00 GHz25 W4C / 4TYes3.00 GHz
XeonE3-1240L v52.10 GHz25 W4C / 8TNo3.20 GHz
XeonE3-1268L v52.40 GHz35 W4C / 8TYes3.40 GHz
XeonE3-1220 v53.00 GHz80 W4C / 4TNo3.50 GHz
XeonE3-1220 v63.00 GHz72 W4C / 4TNo3.50 GHz
XeonE3-1225 v53.30 GHz80 W4C / 4TYes3.70 GHz
XeonE3-1225 v63.30 GHz73 W4C / 4TYes3.70 GHz
XeonE3-1230 v53.40 GHz80 W4C / 4TNo3.80 GHz
XeonE3-1240 v53.50 GHz80 W4C / 8TNo3.90 GHz
XeonE3-1230 v63.50 GHz72 W4C / 8TNo3.90 GHz
XeonE3-1260L v52.90 GHz45 W4C / 8TNo3.90 GHz
XeonE3-1245 v53.50 GHz80 W4C / 8TYes3.90 GHz
XeonE3-1280 v53.70 GHz80 W4C / 8TNo4.00 GHz
XeonE3-1270 v53.60 GHz80 W4C / 8TNo4.00 GHz
XeonE3-1275 v53.60 GHz80 W4C / 8TYes4.00 GHz
XeonE3-1240 v63.70 GHz72 W4C / 8TNo4.10 GHz
XeonE3-1245 v63.70 GHz73 W4C / 8TYes4.10 GHz
XeonE3-1280 v63.90 GHz72 W4C / 8TNo4.20 GHz
XeonE3-1270 v63.80 GHz72 W4C / 8TNo4.20 GHz
XeonE3-1275 v63.80 GHz73 W4C / 8TYes4.20 GHz
XeonE3-1285 v64.10 GHz79 W4C / 8TYes4.50 GHz



Ordering informations

F23611-B2 1u rackmount chassis, C236 Chipset, 6 x GbE RJ45, 2 channels bypass, 250W PSU

F23611-B2P2 1u rackmount chassis, C236 Chipset, 6 x GbE RJ45, 2 channels bypass, 350W redundant PSU
