Home > Instruments & Meters > Test Instrument > Test Machine > VU-2Y Hydraulic Charpy Impact Specimen UV Notch Broaching Machine
VU-2Y Hydraulic Charpy Impact Specimen UV Notch Broaching Machine
US$ 900 - 1,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HST
Place of Origin:
China
Model Number:
VU-2Y
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XJCJ-2B Drop Hammer Tube Impact Testing Equipment , Tubing Materials Drop Weight Impact Test MachineUS$ 3,900 - 6,900MOQ: 1 Set -
XJU Digital Display Nylon Izod Impact Testing Machine/ Charpy Impact Tester for PlasticUS$ 2,500 - 2,600MOQ: 1 Set
-
500J Semi-automatic Charpy Handle Metal Impact Strength Testing MachineUS$ 1,300 - 1,400MOQ: 1 Set
-
JBS-300B Semi-automatic Charpy Impact Test Laboratory Equipment/ Impact TesterUS$ 999 - 2,999MOQ: 1 Set
-
NDT Series Drop Weight Impact Strength Testing MachineUS$ 30,000 - 80,000MOQ: 1 Set
Brand Name
HST
Place of Origin
China
Model Number
VU-2Y
VU-2Y Hydraulic Charpy Impact Specimen UV Notch Broaching Machine
Mobile/whatsapp: +86-15866781190 Skype: hstbetty009
Product Description
VU-2Y Charpy UV Notch Broaching Machine, Metal Making Samples
1. Application
Notch Broaching Machine is necessary and special equipment of metallurgy, pressure vessel, vehicles and vessels, construction machine manufacturer industries and departments of science &research
2.Standards:
ASTM E23-02a,EN10045,ISO148,ISO083,DIN 50115,GB229-2007
3.Features:
3.1 The broach is made of special material and made in special technology, and it has high hardness, good abrasion resistance ability and long serving life;
3.2 This equipment has hydraulic drive double knives and can cut two specimen notches at one time.
4. Main Technical Specifications:
Shape of sample notch | V2 mm,U2mm,(U3mm, U5mm alternative) |
Sample size | (10, 7.5, 5)x10x55mm |
Cutting mode | Hydraulic |
Journey of broach | V2, U2, U3 350mm; U5 380mm |
Broaching Speed | 2.5m/min |
Broach material | W18Cr4V |
Power supply | 380V 50Hz 0.4Kw |
Max. Dimension | 660x500x1240mm |
Weight | 200kg |
