500J Semi-automatic Charpy Handle Metal Impact Strength Testing Machine
US$ 1,300 - 1,400
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HST
Place of Origin:
Shandong, China
Model Number:
JB-500B
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JBS-300B Semi-automatic Charpy Impact Test Laboratory Equipment/ Impact TesterUS$ 999 - 2,999MOQ: 1 Set -
NDT Series Drop Weight Impact Strength Testing MachineUS$ 30,000 - 80,000MOQ: 1 Set
-
300J/500J/800J Impact Testing Machine/charpy Pendulum Impact Tester for Metal Charpy V NotchUS$ 1,900 - 2,100MOQ: 1 Set
-
Hydraulic Impact Specimen U V Notch Cutting MachineUS$ 1,000 - 3,000MOQ: 1 Set
-
DWC-196 Liquid Nitrogen Cooling Chamber for Sample /Cooling Chamber/ChillerUS$ 1,300 - 5,900MOQ: 1 Set
Brand Name
HST
Place of Origin
Shandong, China
Model Number
JB-500B
Power
Electronic
500J Semi-automatic Charpy Handle Metal Impact Tester/ Impact Strength Testing Machine
Contact information: Skype:hstbetty009 Tel: +86-15866781190
Product Description
1. Application
JB type impact testing machine is used for measuring the metal material resistance performance under dynamic load, in order to determine the material properties under dynamic load.
2. Standards:
ISO148, EN10045, ASTM E23, GB/T3808-2002 ,GB/T229-2007
3. Main Technical Specifications:
Model | JB-300B | JB-500B |
Control Way | Electric control | |
impact energy | 300J 150J | 500J 250J |
Minimun read value | 1J | 2J |
Impact speed | 5.2m/s | 5.4 m/s |
Pre-rising angle of the pendulum | 150° | |
Angle accuracy | ±0.1° | |
Specimen bearer span | 40mm | |
Round angle of the jaw | R1.0~1.5mm | |
Round angle of impact edge | R2.0~2.5mm, (R8mm) | |
Impact blade thickness | 16mm | |
The distance between the center of pendulum and impact point |
750mm |
800mm |
Standard specimen dimension | 10mm×10mm(7.5mm/5mm)×55mm | |
Pendulum torque | M=160.7695N.m 80.3848N.m | |
Power supply | three phase four line 380V, 50Hz | |
4. Features:
4.1 The principle machine of the testing machine has single supporting column structure, cantilever type pendulum hanging mode; the pendulum body is U-shaped
4.2 The impact blade is installed and fixed by screws and is convenient and easy to be replaced;
4.3 the specimen is supported adopts simply supported beam type
4.4 S
