Metal Pipe and Rod Chamfering Machine

Name: Metal Pipe and Rod Chamfering Machine
Brand: Chine Chern
Availability: InStock

FOB Price

US$ 5.00 - 15.00 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Chine Chern

Model Number

JC-60SA

Metal pipe and rod chamfering machine

Features:

The clamp mould and knife wheel are designed finished to guarantee the central line of workpiece and knife wheel is exact. Thus, the outer angle, inner angle and pipe end machining may be finished evenly at one time.
It makes use of the change of belt wheel to shift different rotate speeds, so the life of blade may be as long as possible according to different metal materials.
The double-step feeding system saves working time. And the speed is slow for regulating easily.

Technical Parameters:

Model	JC-60SA(Hydraulic item )
Host motor	2HP/4P
Speed (RPM)	90/600 2000/3560
Oil cylinder	0.75KW/20Lite pump,20-30kg/cm2
Standard cutter(Diameter)	12mm-60mm
Processing range(Inner,outer and tube end surface)	Pipe diameter: 3.2mm-60mm Bar outer:6mm-38mm
Suitable Material	Steel pipe,Iron pipe,Stainless steel pipe,Aluminium pipe,Copper pipe
Machine dimension(WDH)	545×655×1080mm
Weight(KG)	220KGS
Accessory	1.one set clamp mould 2. one tool box 3.One user manual

Standard Accessories :

Chamfering Drawing Example:

Machine photo:

Samples:

Package
