SG-II-80 Automatic steel tube end reducing machine with two stations
- 30 Set / Sets per Month
- Shanghai China
- T/T Credit Card
-
Auto exhaust pipe reducer machine also for pipe end reducer and flange
-
Single station automatic hydraulic conical tube end forming machine for fitting one tube into another
-
SG-II-40 Single head steel tube end finishing machine for tube reducing
-
CH-50 Hydraulic steel tube end arc punching machine with different angle notching
-
Hydraulic control horizontal steel tube notcher machine for good welding
-
Automatic stainless steel pipe tube notcher machine
Product Details
| Brand Name: | CARE | Place of Origin: | Jiangsu, China | Model Number: | SG-II-80 tube end reducing machine |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
SG-II-80 Automatic steel tube end reducing machine with two stations
Application: Tube end forming machine is widely used in numerous end forming applications and industries, such as automotive exhausts, furniture, air conditioning, among others. Forming controlled by hydraulic, clamping controlled by hydraulic. PLC controller with English language.
Main specification
1) PLC control Unit: Easy Operation and Maintenance
2) Suitable for the shrinking of various metal pipes with different material and different shape
3) Equipped with emergency stop device. Both manual and automatic operations are available
4) Shrinking stroke 150mm. The max. workpiece length is 450mm, with no minimum workpiece length
5) This machine can make pipe end reducer, expander, flange and flare depend on different forming molds
Technical parameter
Type | SG-40 | SG-60 | SG-80 | SG-100 |
Max tube(mm) | φ40*2.0 | φ60*2.0 | φ80*3.0 | φ100*3.5 |
Max processing length(mm) | 110 | 130 | 150 | 180 |
Oil pressure(Mpa) | 14 | 14 | 14 | 14 |
Working speed | 100mm in3-4/s | 100mm in3-4/s | 100mm in3-4/s | 100mm in3-4/s |
Size(cm) | 180*45*120 | 200*50*130 | 290*70*140 | 300*75*150 |
Weight(kg) | 600 | 950 | 1600 | 1800 |
Remark | 1.The max processing length can according to customers requirement. | |||
Machine photo
Forming molds
Pipe samples
To know more information, please contact us at any time.
