Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh

Feiya International Group.,ltd
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh thumbnail-1
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh thumbnail-2
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh thumbnail-3
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh thumbnail-4
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh thumbnail-5
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh photo-1
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh photo-2
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh photo-3
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh photo-4
Johnson Screen Plate, Stainless Steel Wedge Wire Screen Panels , Vee Wire Welded Johnson Screen Mesh photo-5
US$ 60 - 200 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Brand Name:
feiyatrade, xinlu wire mesh, xinlu wedge wire screen
Place of Origin:
China
Model Number:
to order
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin port, China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name feiyatrade, xinlu wire mesh, xinlu wedge wire screen
Place of Origin China
Model Number to order
Material Metal
Length to order
Thickness 5-50mm
Type Mine Sieving Mesh
Width to order
Usage Solid Filter
Filter Rating 0.1-50mm
Hole Shape Square

Contact Person: Star Lee  86-0-13315867171

MSN: feiyatrade@hotmail.com

E-mail: starlee@feiyaguoji.com


Produce Name: wire wrapped panel, Johnson Screen plate, flat wedge wire panel with frame, Johnson screen flat panel, flat panel screens, sieve bend, arc screen, slot wire screen plate, stainless steel wire sieve, sieving wire mesh, wide slit screens, vibrating sieve screen


Material:Stainless SteelGrade:304
Slot Size:0.7mmDiameter:300 Mm + 450 Mm
Length:500 MmEnd Connection:Weld
Package:Woden Box,Container

High Light:wedge wire sheets, stainless steel wedge wire grates


Vee Wire Welded Solt Johnson Wedge Wire Flat Screen Grids Panel







Product Description:



Vee Wire Welded Solt Johnson Wedge Wire Flat Screen Grids Panel is welded by V wire and support rod.There is a fixed value slot between each v wire. The support bar can be a round wire or a triangular wire or a trapezoidal wire. The sieve is a triangular wire (v-shaped silk). Wire and stainless steel ladder washing coal mine screen mesh with the series: wedge wire slot sieve plate, stainless steel 304 coal seam sieve plate, triangle silk screen plate, trapezoidal wire arc sieve plate, flat screen, high frequency sieve plate, coal washing sieve plate, wear-resisting screen mesh, Johnson screen screen surface.



Specification:


MaterialStainless steel
Grade304
 Dimension3 * 3 m, request
Slot Size0.7 mm
Width up tp 3000mm
Length up to 3150mm
Type screen plate
Wire size2*3.5 mm
Support rod3*4.6 mm
Wire shapeV shape



Regular Specifications:



Material: stainless steel 302, 304, 316, 304L, 316L or low carbon galvanized

Slot: 0.1mm - 35mm

Discrepancy: + / - 0.05mm

Dimension: width up to 3000 mm

                    Length up to 3150mm

Specification of the wrap wire:1 * 2 mm, 2 * 3 mm, 2.2 * 3.5 mm, 3 * 4.6 mm and so on.

Specification of the rod: 2 * 3 mm, 3 * 4.6 mm, 3 * 5 mm, 4 * 4 mm ( square shape ) and so on.

Special specification can be made according to your need.



Advantages:



V-Shaped Slots: Openings shaped like a "v" that open toward the inside of the well tend to allow the particles that are just barely smaller than the width of the slot pass. In other shapes of openings, these particles would get caught in the screen and clog it.
Continuous Slots: The special design gives continuous slot opening across the periphery and length of screen.
Very Large Open Area: This design gives continuous slot and hence the% open area for water to enter is more than 2 times that of conventional slotted pipes of any size and slot opening. This allows more water to enter at much lesser frictional head loss and the efficiency of tube well is improved appreciably.
Energy Saving: Due to reduce frictional head losses and increased discharge, the pump load reduces the power required to pump same quantity of water. Power saving of around 20-25% is observed.



Industry:



Vee Wire Welded Solt Johnson Wedge Wire Flat Screen Grids Panel can be used for filtering and screening of many kinds of media, and it is widely used in multi-industry screening, filtration, dehydration, desilting and so on.

  1.  mining machinery: used for desilting and dewatering of coal preparation plants.

  2.  wheat tooth machine: it is suitable for use in wheat tooth mill, floater and drying stove.

  3.  beer machine: it is suitable for use in the brewery filter tank, with the advantages of high opening rate and long service life.

  4.  huanbao: used for filling oil, gas and Wells with sand and gravel to protect underground and ground equipment.It has the advantages of high opening rate, large filtration area, fast filtration speed and long service life.

  5.  food industry: the filtration process can be used for food and beverage.

  6.  aquaculture: used for farming, cleaning up waste residues from animals.

  7.  chemical industry and other: sewage treatment for sugar mills and paper mills; Material filtration, dehydration and the supporting use of all kinds of painting rooms in chemical fertilizer plant; Starch filtration in the food factory; Ventilation for grain storage.

Product Tags: v wire slot panel , sieve bend screen , dewatering screen panel , wedge wire grating , wire wrapped filter panel , johnson wire screen plate , wedge wire support grids , profile wire screen panel , water filter piece
