Johnson Water Filter Nozzle Thread Size Long Handle Strainer Use For Distributor
Product Description:
| Product Name | Johnson Water Filter Nozzle Thread Size Long Handle Strainer Use For Distributor |
| Material | Stainless Steel |
| Grade | 304 |
| Slot size | 0.25mm |
| Diameter | 53 mm |
| Screen Lenth | 45 mm |
| Total Length | 171 mm |
| Thread Size | 1" 24 mm |
| Nutsert | 1 PCS, 2 PCS |
| Gasket | 1 PCS steel gasket,1 PCS rubber mat |
Characteristic:
Johnson Water Filter Nozzle Thread Size Long Handle Strainer Use For Distributor Used In Water Distributor is welded with Johnson well screen, thread pipe and steel panel through special welding process. The Johnson well screen is the profile wedge wire screen ,the wire and the support rod is V shape , so the screen filter surface outside is smaller than inside, so that the screen nozzle is not easy to jam. The thread pipe is made by international standard.1 “,1 1/4 “, 2 1/4 “ and so on.
OEM service:
Stainless Steel 304 Johnson Screen Filter Nozzle Used In Cloth Degasser support OEM
Please tell us the specification of the water cap you need and we will help you to process the high quality products.
Custom range
Material: mainly stainless steel 304, 316L, 321, Hastelloy B, C and other materials.
Gap: 0.2-0.25mm, can be according to customer needs.
Use:
Stainless Steel 304 Johnson Screen Filter Nozzle Used In Cloth Degasser is American technology.
The water cap is often installed with porous plates and placed in the filter tube body , which has a good effect on various liquids such as filter resin, liquid and silica gel .
water treatment, chemical, petrochemical, pharmaceutical, biotechnology, power plant, ion exchange, yin-yang bed, mixed bed.
Regular Specifications:
| Type | Slot size | Specifications |
Flow filter area 0.2mm slot ( reference) |
|||
| D | H | L | M | |||
| FY-XL-PT-45-A | 0.2-0.5 | 45 | 25 | 90 | 25 | 280 |
| FY-XL-PT-45-B | 0.2-0.5 | 45 | 35 | 100 | 25 | 380 |
| FY-XL-PT-45-C | 0.2-0.5 | 45 | 45 | 110 | 25 | 550 |
| FY-XL-PT-45-D | 0.2-0.5 | 45 | 35 | 55 | 25 | 380 |
| FY-XL-PT-45-E | 0.2-0.5 | 45 | 45 | 65 | 25 | 550 |
| FY-XL-PT-53-A | 0.2-0.5 | 53 | 35 | 100 | 25 | 450 |
| FY-XL-PT-53-B | 0.2-0.5 | 53 | 45 | 110 | 25 | 580 |
| FY-XL-PT-53-C | 0.2-0.5 | 53 | 55 | 120 | 32 | 700 |
| FY-XL-PT-57-A | 0.2-0.5 | 57 | 35 | 100 | 32 | 530 |
| FY-XL-PT-57-B | 0.2-0.5 | 57 | 45 | 110 | 32 | 680 |
| FY-XL-PT-57-C | 0.2-0.5 | 57 | 55 | 120 | 32 | 830 |
| FY-XL-PT-70-A | 0.2-0.5 | 70 | 40 | 105 | 32 | 650 |
| FY-XL-PT-70-B | 0.2-0.5 | 70 | 55 | 115 | 32 | 810 |
