V Shape Wire Slot Wedge Wire Screen Panels For Solid-liquid separation
Sieve Bend
Features: Low Headroom - only 1.1 metres (44") tall for the 900 mm arc length unit.
Energy Efficient - operates with no moving parts and with no energy input.
Space Efficient - treats up to 122 litres per second per square metre of floor space.
Quiet Operation - no moving parts means no mechanical or electrical vibrations.
Accurate Sizing - can be used for sizing solid particles down to 0.2 mm (0.008").
Low Maintenance - the profile wire screen resists clogging by near-size particles, and the all-stainless steel construction ensures a long, corrosion-free installation.
Easy Screen Replacement - a typical screen can be replaced in 10 minutes with no tools.
Flexible Design - we can supply units with any features you may require.
V Shape Wire Slot Wedge Wire Screen Panels Specification:
| Material | Stainless steel |
| Grade | 304 |
| Dimension | 3 * 3 m, request |
| Slot Size | 0.7 mm |
| Width | up tp 3000mm |
| Length | up to 3150mm |
| Type | screen plate |
| Wire size | 2*3.5 mm |
| Support rod | 3*4.6 mm |
| Wire shape | V shape |
V Shape Wire Slot Wedge Wire Screen Panels Regular Specifications:
V Shape Wire Slot Wedge Wire Screen Panels For Solid-liquid separation
Material: stainless steel 302, 304, 316, 304L, 316L or low carbon galvanized
Slot: 0.1mm - 35mm
Discrepancy: + / - 0.05mm
Dimension: width up to 3000 mm
Length up to 3150mm
Special specification can be made according to your need.
V Shape Wire Slot Wedge Wire Screen Panels Advantages:
V Shape Wire Slot Wedge Wire Screen Panels For Solid-liquid separation
Wedge wire and support rod adopt the international advanced continuity resistance welding technology automation mine screen mesh welding production equipment, sieve seam even, stable welding quality, wear-resisting, long service life and has a high strength, stiffness and bearing capacity, can make various shapes of the rigid screening filter device. And the screen seam is v - shaped, easy to leak, not easy to plug.
Industry:
V Shape Wire Slot Wedge Wire Screen Panels For Solid-liquid separation are mainly used for screening filter coal mine, coal products, such as iron ore, sandstone can also be used for food, oil, water and other solid liquid filter, mainly used in coal mine, coal washing, food, is a manufacturing and other industries, can also be used to decorate the breeding, etc.
