Home > Products > Electrical Instruments > UNI-T UT203 UT 203 Digital Clamp Multimeter Ohm DMM DC AC Current Voltmeter 400A
UNI-T UT203 UT 203 Digital Clamp Multimeter Ohm DMM DC AC Current Voltmeter 400A
Negotiable
/ Piece
10 Pieces(Min. Order)
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
KYORITSU Digital Earth Resistance Tester 4105A-H Multimeter With Hard Case
-
KYORITSU 4102A Digital Earth Testers Electric Ground Resistance Meters 1200ohm
-
KYORITSU 1009 Handheld Digital Multimeter 4000 Counts Display 10A Ac/dc
-
KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V
-
KYORITSU 2002PA AC Digital Clamp Meters up to 2000A Peak Hold
-
KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter
Product Details
| Place of Origin | Guangdong, China | Brand Name | UNI-T | |
| Model Number | UT203 | Display Type | Digital Only | |
| Measuring Current Range | 400A | Measuring Voltage Range | 600V | |
| Measuring Resistance Range | 40MΩ | Operating Temperature | -40 °C ~ 1000°C ±(2.5%+3) | |
| Dimensions | 210 x 75.6 x 30mm | Weight | 200g |
Product Description
UNI-T UT203 UT 203 Digital Clamp Multimeter Ohm DMM DC AC Current Voltmeter 400A
SPECIFICATIONS
Basic Functions | Range | Best Accuracy |
| DC Voltage | 400mV/4V/40V/400V/600V | ±(0.8%+1) |
| AC Voltage | 4V/40V/400V/600V | ±(1%+5) |
| DC Current | 40A/400A | ±(2%+3) |
| AC Current | 40A/400A | ±(2.5%+5) |
| Resistance | 400W/4kW/40kW/400kW/4MW/40MW | ±(1%+2) |
| Frequency | 10Hz~1MHz | ±(0.1%+3) |
| Duty Cycle | 0.1%~99.9% | √ |
| Special Functions | ||
| Auto Ranging | √ | |
| Diode | √ | |
| Continuity Buzzer | √ | |
| Data Hold | √ | |
| Full Icon Display | √ | |
| Sleep Mode | √ | |
| Low Battery Display | √ | |
Input Impedance for | Around 10MW | √ |
| Max. Display | 3999 | √ |
GENERAL CHARACTERISTICS
| Power | 9V Battery (6F22)(not include) |
| LCD Size | 35.6 x 18 mm |
| Product Colour | Red and Grey |
| Product Net Weight | 200g |
| Product Size | 210 x 75.6 x 30mm |
| Standard Accessories | Test Lead, English Manual, Carrying Bag |
| Standard Individual Packing | Gift Box |
| Standard Quantity Per Carton | 40 pcs |
| Standard Carton Measurement | 510 x 490 x 330mm |
| Standard Carton Gross Weight | 15kg |
