Home > Instruments & Meters > Test Instrument > Test Machine > UNI-T UT526 Multi-Functional Electrical Insulation Tester Earth Resistance Meter + 1000V+RCD Tester+Continuity+Vac/dc (4 in 1)
UNI-T UT526 Multi-Functional Electrical Insulation Tester Earth Resistance Meter + 1000V+RCD Tester+Continuity+Vac/dc (4 in 1)
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT526
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
4 in 1 Insulation Tester Earth Resistance Meter+1000V+RCD+Continuity+ac/dc UT526NegotiableMOQ: 1 Piece -
Kyoritsu KEW SNAP 200 DIGITAL DISPLAY AC DC Clamp Meter TesterNegotiableMOQ: 1 Piece
-
UNI-T UT171B Industrial True RMS Digital Multimeter 60KCounts Admittance nS EBTN USBUS$ 150 - 190MOQ: 1 Piece
-
UNI-T UT71D Intelligent Digital Multimeter Volt Amp Ohm Capacitance Meter Thermometer With USBUS$ 100 - 130MOQ: 1 Piece
-
UNI-T UT805A LCD USB Bench Top Digital Multimeter Volt Amp Ohm Capacitance Hz TesterNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT526
UNI-T UT526 Multi-Functional Electrical Insulation Tester Earth Resistance Meter + 1000V+RCD Tester+Continuity+Vac/dc (4 in 1)
Detailed
UT525 are newly designed digital multi-functional testing meters adopted large-scale integrated analog/digital
circuit and Micro-processing chip. UT525 are highly accurate, reliable, and user-friendly. They are your ideal tools
to test the parameters of residual current device (RCD), earth resistance, insulation resistance, DC and AC
voltage. UT520 series complies with the over voltage standard (CAT III 600V).
Contrast
| Specifications | Range | Best Accuracy | ||
| Model | UT525 | UT526 | ||
| Insulation Resistance(Ω) | Test Voltage | 100V/250V/500V | ±10% | |
| 250V/500V/1000V | ±10% | |||
| 100V | 0.05MΩ-200MΩ | ±(5%+5) | ||
| 250V | 0.05MΩ-200MΩ | ±(5%+5) | ±(5%+5) | |
| 500V | 0.05MΩ-200MΩ | ±(5%+5) | ||
| 0.05MΩ-300MΩ | ±(5%+5) | |||
| 1000V | 0.05MΩ-500MΩ | ±(5%+5) | ||
| Test Current | 100V(R=100KΩ) 1mA | ±10% | ||
| 250V(R=250KΩ) 1mA | ±10% | ±10% | ||
| 500V(R=500KΩ) 1mA | ±10% | ±10% | ||
| 1000V(R=1MΩ) 1mA | ±10% | |||
| Short Circuit Current: | <2mA | √ | √ | |
| RCD | Operational Voltage(Freq.) | 220V(45Hz--65Hz) | ±10% | ±10% |
| Test Current | 10mA/30mA/100mA/300mA | 0-10% | 0-10% | |
| Trip Time | 0ms-2000ms, 1Δn Genetal(10mA) | ±(5%+2) | ±(5%+2) | |
| 0ms-500ms, 1Δn Genetal(300mA) | ||||
| 0ms-300ms, 1Δn Genetal100mA,300mA | ||||
| Low Resistance Continuity(Ω) | Range | 0.00Ω~200Ω | ±(2%+5) | |
| 0.00Ω~2000Ω | ±(2%+5) | |||
| Test Voltage | Around 5.0V | √ | √ | |
| Test Current | >200mA(R<2Ω) | √ | √ | |
| Voltage Mesurement(V) | DC Voltage | 0-440V | ±(2%+3) | ±(2%+3) |
| AC Voltage | 0-440V | ±(2%+3) | ±(2%+3) | |
| Frequency (Reference Only) | √ | √ | ||
| Features | ||||
| Display Count | 9999 | 9999 | ||
| Manual Range | √ | √ | ||
| Phase Switch(RCD) | 0°and 180° | √ | √ | |
| Low Battery Indication | √ | √ | ||
| Automatically Selects DCV or ACV | √ | √ | ||
| Red Warning Lights | √ | √ | ||
| General Characteristic | ||||
| Power | 1.5V Alkaline Batteries(LR6×6) | |||
| LCD Size | 71mm X 34mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 380g | |||
| Product Size | 160mm X 100mm X 71mm | |||
| Standard Accessories | Test Lead,Batteries, Carrying Bag, Alligator Clip | |||
| Standard Individual Packing | Gift Box, English Manual | |||
| Standard Quantity Per Carton | 20 PCs | |||
| Standard Carton Measurement | 400mm X 430mm X 335mm(0.063CBM Per Export Carton) | |||
| Standard Carton Gross Weight | 16 Kg | |||
Fitting
1. Test Lead,
2. Batteries,(not included)
3. Carrying Bag,
4. Alligator Clip
(Julie Zhou)
