Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD Multimeter

Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD Multimeter photo-1
Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD Multimeter photo-2
Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD Multimeter photo-3
Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD Multimeter photo-4
Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD Multimeter photo-5
Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD Multimeter photo-6
US$ 1 - 32 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT210E
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name UNI-T
Model Number UT210E
Display Type Digital Only
Measuring Current Range 2A/20A/100A
Measuring Voltage Range 600V
Measuring Resistance Range 20MΩ
Measuring Capacitance Range 20mF
Operating Temperature -40 °C ~ 1000°C ±(2.5%+3)
Dimensions 175mm*60mm*33.5mm
Weight 170g

Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD Multimeter

Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD Multimeter











Detailed



UT210 series Mini Clamp is provided with the features of high reliability, security, auto range , and small-size. It can test the small current signal precisely; the chip itself has VFC start-up model, and there is a Specific filter circuit inside, which can filter the high frequency interference signal and ensure the accuracy of the measurement. It can be applied in the situation such as variable frequency voltage and current with VFC .It has the design of full range of overload protection ,along with the unique exterior design, which makes it a more remarkable new practical electric testing instrument. UT210 series Mini Clamp is an ideal tool that can be applied to colleges and universities, smelting, telecommunications, manufacturing, oil,defense, power, foundry, circuit of power equipment inspection, and maintenance and repairs.

UT210E (Main features)

1. Ultra-portable tools for advance electricians
2. 100A AC and DC current measurement with 1mA resolution
3. True RMS response for AC current
4. V.F.C function for measuring signal at variable frequency
5. 600V AC and DC voltage measurement
6. Resistance, diode, continuity and capacitance functions
7. Non-contact voltage detection with LED indication
8. Display backlight
9. Data HOLD, MAX, MIN, MAX-MIN, and ZERO model





Paraeter


Specifications Range Best Accuracy
Model   UT210E
AC Current(A) 2A/20A/100A ±(2.5%+5)
DC Current(A) 2A/20A/100A ±(2%+3)
AC Voltage(V) 2V/20V/200V/600V ±(1%+3)
DC Voltage(V) 200mV/2V/20V/200V/600V ±(0.7%+3)
Resistance(Ω) 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ ±(1%+2)
Capacitance(F) 2nF/20nF/200nF/2μF/20μF/200μF/2mF/20mF ±(4%+5)
Features
Display Count   2000
Auto Range
Jaw Capacity   17mm
Ture RMS
Diode Around 3.0V
V.F.C.
NCV
Date Hold
Zero Mode
LCD Backlight
Auto Power Off Around 15 Minutes
Continuity Buzzer
Low Battery Indication ≤2.5V
Input Protection
Input Impedance for DCV ≥10MΩ
General Characteristic
Power AAA 1.5V Battery×2pcs (Battery not included)
LCD Size 39.3mm×26.5mm
Product Color Red and Grey
Product Net Weight 170g
Product Size 175mm×60mm×33.5mm
Standard Accessories Test Lead, Carrying Bag
Standard Individual Packing Gift Box, English User Manual
Standard Quantity Per Carton 40Pcs
Standard Carton Measurement 385mm×345mm×305mm(0.041CBM Per Standard Carton)
Standard Carton Gross Weight 11Kg
