Bench Type Digital Multimeters UNI-T UT801 Automatic Range True Valid Values Average Value Display
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT801
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UT803 5999 Counts 100kHz True RMS Bench Type Digital Multimeter With RS232C/USB Interface, LCD Backlight Display, Data HoldNegotiableMOQ: 1 Piece -
Uni-t UT253A Professional 1200A Large Jaws Leakage Current Tester Clamp Meter W/RS232NegotiableMOQ: 1 Piece
-
UNI-T UT233 Three Phase 600KW Power Clamp Meter True RMS Digital Clamp Meter USBNegotiableMOQ: 1 Piece
-
UNI-T UT805A Digital Bench Multimeter High-accuracy 0.015% True RMS USB RS232NegotiableMOQ: 1 Piece
-
UNI-T UT526 Multi-Functional Electrical Insulation Tester Earth Resistance Meter + 1000V+RCD Tester+Continuity+Vac/dc (4 in 1)NegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT801
Measuring Current Range
10A
Measuring Voltage Range
1000V
Measuring Resistance Range
20MΩ
Measuring Capacitance Range
200uF
Operating Temperature
-40°C - 1000°C
Dimensions
300mm * 245mm * 105mm
Bench Type Digital Multimeters UNI-T UT801 automatic range True Valid Values average value display
Description
UT801 is a manual range digital bench-type multimeter with average value display, full function and full range overload protection and a unique outlook design. It can be powered by AC 220V/50Hz or 1.5V batteries(R14)*6. It’s your ideal testing meter with superior performance.
UT801 is widely used in Industrial Production and Service, Technological Research and Design, College Education (Laboratory, Courses), and Automotive Industry. The meter complies with IEC61010-1 standard, CATII 1000V.
Technicial Parameters
| Specifications | Range | Best Accuracy | |
| Model | UT801 | UT802 | |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | ±(0.5%+2) | ±(0.1%+3) |
| AC Voltage (V) | 2V/20V/200V/750V | ±(0.8%+3) | ±(0.5%+20) |
| DC Current (A) | 200μA/2mA/20mA/200mA/10A | ±(0.8%+2) | ±(0.5%+20) |
| AC Current (A) | 2mA/20mA/200mA/10A | ±(1.0%+3) | ±(0.8%+40) |
| Resistance (Ω) | 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ | ±(0.8%+3) | |
| 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/200MΩ | ±(0.5%+10) | ||
| Capacitance (F) | 20nF/2μF/200μF | ±(4%+3) | ±(4%+10) |
| Frequency (Hz) | 2kHz/200kHz | ±(1.5%+5) | ±(1.2%+10) |
| Temperature (°C) | -40 °C~1000°C | ±(1.2%+3) | ±(1.2%+25) |
| Features | |||
| Display Count | 2000 | 20000 | |
| Manual Range | √ | √ | |
| Diode | √ | √ | |
| Transistor | √ | √ | |
| Continuity Buzzer | √ | √ | |
| Low Battery Indication | √ | √ | |
| Data Hold | √ | √ | |
| LCD Backlight | √ | √ | |
| Input Impedance for DCV | Around 10MΩ | √ | √ |
| Misuse Alarm | √ | √ | |
| General Characteristic | |||
| Power | AC 220V/50Hz or 1.5V Batteries (R14)×6 | ||
| LCD Size | 108mm × 34.5mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 1650g | ||
| Product Size | 300mm × 245mm × 105mm | ||
| Standard Accessories | Battery, Test Lead,Alligator Clip, Point Contact Temperature Probe, Multi-Purpose Socket, AC 220V Power Cord, Power Adapter |
||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 4 PCs | ||
| Standard Carton Measurement | 680mm×365mm×320mm(0.0794 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 11.7 Kg | ||
Accessories
- Battery, (not included)
- Test Lead,
- Alligator Clip,
- Point Contact Temperature Probe,
- Multi-Purpose Socket,
- AC 220V Power Cord,
- Power Adaper
