UNI-T UT71D Intelligent Digital Multimeter Volt Amp Ohm Capacitance Meter Thermometer With USB
US$ 100 - 130
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT71D
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UT805A LCD USB Bench Top Digital Multimeter Volt Amp Ohm Capacitance Hz TesterNegotiableMOQ: 1 Piece -
Mini Digital Clamp Meter UT210E Ture RMS Auto Range 2000 LCD MultimeterUS$ 1 - 32MOQ: 5 Pieces
-
UNI-T UT181A True RMS Datalogging Multimeters 60000 COUNTS DMM Capacitance MeterNegotiableMOQ: 1 Piece
-
UNI-T UT71E Intelligent LCD Digital Multimeter With USB Interface Frequency Tester Meter 39999 MaxUS$ 100 - 160MOQ: 1 Piece
-
Multifunctions Electric Meters UNI-T UT525 Electrical Insulation Tester+RCD Tester+Continuity+VAC/DC (4 in 1)US$ 1 - 110MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT71D
Measuring Current Range
400μA-10A
Measuring Voltage Range
400mV-1000V
Measuring Resistance Range
200Ω - 20MΩ
Measuring Capacitance Range
40nF-40mF
Operating Temperature
-40 °C - 1000°C
Dimensions
200mm * 93mm * 40 mm
UNI-T UT71D Intelligent Digital Multimeter Volt Amp Ohm Capacitance meter thermometer with USB
Technical Specifications:
| Specifications | Range | Best Accuracy |
| Model | UT71D | |
| DC Voltage (V) | 400mV/4V/40V/400V/1000V | ±(0.025%+5) |
| AC Voltage (V) | 4V/40V/400V/1000V | ±(0.4%+30) |
| DC Current (A) | 400μA/4000μA/40mA/400mA/10A | ± (0.1%+15) |
| AC Current (A) | 400μA/4000μA/40mA/400mA/10A | ± (0.7%+15) |
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(0.3%+8) |
| Capacitance (F) | 40nF/400nF/4μF/40μF/400μF/4mF/40mF | ±(1%+20) |
| Frequency (Hz) | 40Hz-400MHz | ±(0.01%+8) |
| Temperature (°C) | -40 °C ~ 1000°C | ±(1%+30) |
| Temperature (°F) | -40°F~1832°F | ±(1.5%+50) |
| Features | ||
| Display Count | 39999 | |
| Auto Range | √ | |
| True RMS | √ | |
| Bandwidth (Hz) | 100KHz | √ |
| Duty Cycle | 10% ~ 90% | ±(1%+30) |
| Diode | √ | |
| Auto Power Off | √ | |
| Continuity Buzzer | √ | |
| Low Battery Indication | √ | |
| Data Hold | √ | |
| Relative Mode | √ | |
| MAX/MIN | √ | |
| Data Logging | 9999 | |
| USB Interface | √ | |
| Double Backlight | √ | |
| Analogue Bar Graph | √ | |
| Full Icon Display | √ | |
| Setup | √ | |
| Input Impedance for DCV | DC 400mV: Around 2.5GΩ,All Other Range: 10MΩ | √ |
| 4 - 20mA Loop | 0~100% | ±(1%+50) |
| Fused 10 A | √ | |
| Current Measurement Alarm | √ | |
| Voltage & Current AC+DC Measurement | √ | |
| General Characteristic | ||
| Power | 9V Battery(6F22) | |
| LCD Size | 73mm X 50 mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 384g | |
| Product Size | 200mm X 93mm X 40 mm | |
| Standard Accessories | Battery, Test Lead, Alligator Clip, Test Clip, USB Interface Cable,PC Software CDe,Carrying Bag, Point Contact Temperature Probe | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 20 PCs | |
| Standard Carton Measurement | 530mm X 360mm X 385mm (0.073 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 22 Kg | |
Accessories
Battery, (not included)
Test Lead,
Alligator Clip,
Test Clip,
USB Interface Cable,
PC Software CDe,
Carrying Bag,
Point Contact Temperature Probe
