UT803 5999 Counts 100kHz True RMS Bench Type Digital Multimeter With RS232C/USB Interface, LCD Backlight Display, Data Hold
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT803
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Uni-t UT253A Professional 1200A Large Jaws Leakage Current Tester Clamp Meter W/RS232NegotiableMOQ: 1 Piece -
UNI-T UT233 Three Phase 600KW Power Clamp Meter True RMS Digital Clamp Meter USBNegotiableMOQ: 1 Piece
-
UNI-T UT805A Digital Bench Multimeter High-accuracy 0.015% True RMS USB RS232NegotiableMOQ: 1 Piece
-
UNI-T UT526 Multi-Functional Electrical Insulation Tester Earth Resistance Meter + 1000V+RCD Tester+Continuity+Vac/dc (4 in 1)NegotiableMOQ: 1 Piece
-
4 in 1 Insulation Tester Earth Resistance Meter+1000V+RCD+Continuity+ac/dc UT526NegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT803
Measuring Current Range
10A
Measuring Voltage Range
1000V
Measuring Resistance Range
60MΩ
Measuring Capacitance Range
6mF
Operating Temperature
-40°C - 1000°C
Dimensions
300mm * 245mm * 105mm
UT803 5999 Counts 100kHz True RMS Bench Type Digital Multimeter with RS232C/USB Interface, LCD Backlight Display, Data Hold
Description
UT803 is a manual range digital bench-type multimeter with average value display, full function and
full range overload protection and a unique outlook design. It can be powered by AC 220V/50Hz or
1.5V batteries(R14)*6. It’s your ideal testing meter with superior performance.
UT802 is widely used in Industrial Production and Service, Technological Research and Design,
College Education (Laboratory, Courses), and Automotive Industry. The meter complies with
IEC61010-1 standard, CATII 1000V.
Technicial Parameters
| Specifications | Range | Best Accuracy | |
| Model | UT803 | UT804 | |
| DC Voltage (V) | 600mV/6V/60V/600V/1000V | ±(0.3%+2) | |
| 400mV/4V/40V/400V/1000V | ±(0.025%+5) | ||
| AC Voltage (V) | 600mV/6V/60V/600V/1000V | ±(0.6%+5) | |
| 4V/40V/400V/1000V | ±(0.4%+30) | ||
| DC Current (A) | 600μA/6000μA/60mA/600mA/10A | ±(0.5%+3) | |
| 400μA/4000μA/40mA/400mA/10A | ±(0.1%+15) | ||
| AC Current (A) | 600μA/6000μA/60mA/600mA/10A | ±(1%+5) | |
| 400μA/4000μA/40mA/400mA/10A | ±(0.7%+15) | ||
| Resistance (Ω) | 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ | ±(0.5%+2) | |
| 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ | ±(0.3%+40) | ||
| Capacitance (F) | 6nF/60nF/600nF/6μF/60μF/600μF/6mF | ±(2%+5) | |
| 40nF/400nF/4μF/40μF/400μF/4mF/40mF | ±(1%+20) | ||
| Frequency (Hz) | 6kHz/60kHz/600kHz/6MHz/60MHz | ±(0.1%+3) | |
| 40Hz/400Hz/4kHz/40kHz/400kHz/4MHz/40MHz/400MHz | ±(0.01%+8) | ||
| Temperature (°C) | -40 °C~1000°C | ±(1%+3) | ±(1%+30) |
| Temperature (°F) | -40°F~1832°F | ±(1.5%+5) | ±(1.5%+50) |
| Features | |||
| Display Count | 6000 | 40000 | |
| Auto Range | √ | √ | |
| True RMS | √ | ||
| Bandwidth (Hz) | 100kHz | √ | √ |
| Duty Cycle | 0~100% | ±(1.0%+40) | |
| Diode | √ | √ | |
| Transistor | √ | ||
| Auto Power Off | √ | √ | |
| Continuity Buzzer | √ | √ | |
| Low Battery Indication | √ | √ | |
| Data Hold | √ | √ | |
| Relative Mode | √ | ||
| MAX/MIN | √ | √ | |
| Peak Hold | √ | ||
| Data Logging | 9999 | ||
| Data Recall | √ | ||
| RS-232 | √ | √ | |
| USB Interface | √ | √ | |
| LCD Backlight | √ | ||
| Double Backlight | √ | ||
| Analogue Bar Graph | 81 | ||
| Setup | √ | ||
| Input Protection | √ | √ | |
| Input Impedance for DCV | 600mV Range: Around 3GΩ ,All Other Ranges: Around 10MΩ | √ | |
| 400mV Range: Around 4GΩ, All Other Ranges: Around 10MΩ | √ | ||
| Current Measurement Alarm | √ | ||
| 4 - 20mA Loop | 0~100% | ±(1%+50) | |
| Voltage &Current: AC+DC Measurement | √ | √ | |
| General Characteristic | |||
| Power | AC 220V/50Hz or 1.5V Batteries (R14)×6 | ||
| LCD Size | 128mm × 28mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | UT803-2.4Kg,UT804-2.2 Kg | ||
| Product Size | 310mm × 240mm × 105mm | ||
| Standard Accessories | UT803-Test Lead,AC 220V Power Cord,Software, RS-232 Interface Cable, USB Interface Cable,Alligator Clip,Point Contact Temperature Probe,Multi-Purpose Socket | ||
| UT804-Test Lead, AC 220V Power Cord, Software, RS-232 Interface Cable, USB Interface Cable, Alligator Clip, Point Contact Temperature Probe, Test Clip | |||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 4 PCs | ||
| Standard Carton Measurement | 680mm×365mm×320mm(0.0794 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 15 Kg | ||
Accessories
1. Test Lead,
2. AC 220V Power Cord,
3. Software,
4. RS-232 Interface Cable,
5. USB Interface Cable,
6. Alligator Clip,
7. Point Contact Temperature Probe,
8. Multi-Purpose Socket
