UNI-T UT181A True RMS Datalogging Multimeters 60000 COUNTS DMM Capacitance Meter
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT181A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UT71E Intelligent LCD Digital Multimeter With USB Interface Frequency Tester Meter 39999 MaxUS$ 100 - 160MOQ: 1 Piece -
Multifunctions Electric Meters UNI-T UT525 Electrical Insulation Tester+RCD Tester+Continuity+VAC/DC (4 in 1)US$ 1 - 110MOQ: 1 Piece
-
Digital RCD Tester Smart Sensor AR5406 Leakage Tester Leakage Current TestUS$ 1 - 150MOQ: 1 Piece
-
Smart Sensor AR907A+ 100-2500V Digital Insulation Meter Tester Megger MegOhm !!NEW!! AC / DC Voltage TesterNegotiableMOQ: 1 Piece
-
Uni-T UT231 Single-phase 2-wire True RMS Power Clamp Meter Power Factor Phase Angle 600KW USB Data Logging Analogue Bar GraphUS$ 50 - 150MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT181A
Measuring Current Range
600μA-10A
Measuring Voltage Range
60mV-1000V
Measuring Resistance Range
600Ω-60MΩ
Measuring Capacitance Range
6nF-60mF
Measuring Inductance Range
none
Operating Temperature
-40 °C - 1000°C
Dimensions
103mm * 225mm * 59mm
UNI-T UT181A True RMS Datalogging Multimeters 60000 COUNTS DMM Capacitance Meter
Features:
1. 60000 display count, 320X240 3.5”TFT full color LCD, Multi-function selection menu, displaying multiple sets of test data simultaneously;2. AC/DC Voltage, AC/DC current, resistance, conductance, diode, capacity, frequency, duty cycle, pulse width, temperature(℃/℉) ;
3. True RMS, Ac voltage bandwidth 100KHz, Ac Current bandwidth 100KHz, alternative AC/DC measurement;
4. Single record data with time remarked, max data logging is 20000,checking and deleting the data;
5. Continuous record data with time remarked, max data logging is 20000. Checking the data by tracing the trend chart, which makes it possible to detect the abnormal signal with the supervisors,Naming, checking and deleting the records;
6. Time signal can make in capture wave form under maximum mode / minimum mode / average mode;
7. In sync on step wave signal;
8. Measuring current can reach at 20A (switch on 30s, pause 10seconds);
9. Using USB(standard accessory) to connect to PC to proceed USB communication . It can use Bluetooth module(alternative accessory) to proceed Bluetooth communication with cellphone;
10. Having the function of alarming when test-lead misplug. Double injection safety shell and IP 65 waterproof.;
11. Help Menu, offering convenient instruction for users;
12. Rechargeble Lithium battery, having long lifetime.
Technical Specifications
| Specifications | Range | Best Accuracy |
| Model | UT181A | |
| DC Voltage (V) | 60mV/600mV/6V/60V/600V/1000V | ±(0.025%+5) |
| AC Voltage (V) | 60mV/600mV/6V/60V/600V/1000V | ±(0.3%+30) |
| DC Current (A) | 600μA/6000μA/60mA/600mA/10A | ±(0.08%+10) |
| AC Current (A) | 600μA/6000μA/60mA/600mA/10A | ±(0.6%+20) |
| Resistance (Ω) | 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ | ±(0.05%+2) |
| Admittance(nS) | 60nS | ±(2%+10) |
| Capacitance (F) | 6nF/60nF/600nF/6μF/60μF/600μF/6mF/60mF | ±(2%+5) |
| Frequency (Hz) | 10Hz-60MHz | ±(0.01%+5) |
| Temperature (°C) | -40 °C~1000°C | ±(1%+30) |
| Temperature (°F) | -40°F~1832°F | ±(1.5%+50) |
| Features | ||
| Display Count | 60000 | |
| Auto Range | √ | |
| Manual Range | √ | |
| True RMS | √ | |
| Bandwidth (Hz) | 100kHz | √ |
| AC + DC | √ | |
| Low Pass Filter | 1KHz(-3db) | √ |
| dBV/dBm | √ | |
| Continuity Buzzer | √ | |
| Diode | Around 3V | √ |
| Duty Cycle | 10% ~ 90% | √ |
| Dual Temperature Measurement | T1,T2, T1-T2,T2-T1 | √ |
| Data Hold | √ | |
| Peak Hold | √ | |
| Relative Mode | √ | |
| Data Logging | 20000 | √ |
| Trend Capture | √ | |
| MAX/MIN/AVG | √ | |
| Date Time Display | √ | |
| Data Comparsion | √ | |
| Display Type | 3.5 Inches 64k Color TFT LCD (320 * 240) | √ |
| Backlight Adjustment | √ | |
| Analogue Bar Graph | 61 | √ |
| USB Interface | √ | |
| Mis-Plug Alarm | √ | |
| Low Battery Indication | √ | |
| Auto Power Off | √ | |
| Re-Chargeable Battery | √ | |
| Input Protection | √ | |
| Input Impedance for DCV | Around 10MΩ | √ |
| General Characteristic | ||
| Power | 7.4V 2200mAh Li-Battery | |
| LCD Size | 70mm × 52mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 638.6 g | |
| Product Size | 103mm × 225mm × 59mm | |
| Standard Accessories | Batteries, Test Lead, Temperature Adaptor, Point Contact Temperature Probe × 2, Power Adaptor, PC Software CD, USB Interface Cable | |
| Standard Individual Packing | Gift Box, Carrying Bag, English Manual | |
| Standard Quantity Per Carton | 20PCs | |
| Standard Carton Measurement | 480mm×385mm×505mm (0.085 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 26.5 Kg | |
| Optional Accessories* | Bluetooth Adaptor (UT-D07) | |
Accessories
Batteries,
Test Lead,
Temperature Adaptor,
Point Contact Temperature Probe × 2,
Power Adaptor,
PC Software CD,
USB Interface Cable
