KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A

KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A thumbnail-1
KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A thumbnail-2
KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A thumbnail-3
KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A thumbnail-4
KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A thumbnail-5
KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A photo-1
KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A photo-2
KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A photo-3
KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A photo-4
KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
KYORITSU
Model Number:
KEW 2003A
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Japan
Brand Name KYORITSU
Model Number KEW 2003A
Display Type Digital Only
Measuring Current Range 2000A
Measuring Voltage Range 1000V
Measuring Resistance Range 4kΩ
Dimensions 250(L) * 105(W) * 49(D)mm
Weight 530g



KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A



KYORITSU KEW 2003A AC DC Current Voltage Digital Clamp Meters Tester 2000A







• Equipped to measure both AC and DC current with transformer jaws of large diameter.
• Can measure AC and DC currents up to 2000A.
• Output terminal for connection to recorders.
AC A 400A/2000A (0 - 1000A)
±1.5%rdg±2dgt [50/60Hz]
±3%rdg±4dgt [40 - 500Hz]
±5%rdg±4dgt [500Hz - 1kHz]
2000A (1001 - 2000A)
±3%rdg±2dgt [50/60Hz]
DC A 400/2000A ±1.5%rdg±2dgt
AC V 400/750V
±1.5%rdg±2dgt [50/60Hz]
±1.5%rdg±4dgt [40Hz - 1kHz]
DC V 400/1000V ±1%rdg±2dgt
Ω 400/4000Ω ±1.5%rdg±2dgt
Continuity buzzer buzzer sounds below 50±35Ω
Conductor size Ø55mm max.
Frequency response 40Hz - 1kHz
Output Recorder :
DC400mV against AC/DC400A
DC200mV against AC/DC2000A
Safety Standard IEC 61010-1 CAT IV 600V , CAT III 1000V
IEC 61010-031
IEC 61010-2-032
Power source R6 (AA) (1.5V) × 2
Dimensions 250(L) × 105(W) × 49(D)mm
Weight 530g approx.
Included Accessories 7107A (Test leads)
8201 (Output Plug)
9094 (Carrying Case)
R6 (AA) × 2
Instruction Manual
Optional Accessories 8008 (Multi-Tran) (AC only)
7256 (Output cord)
