Uni-T UT231 Single-phase 2-wire True RMS Power Clamp Meter Power Factor Phase Angle 600KW USB Data Logging Analogue Bar Graph
Parameter:
Basic Functions |
Range |
Best Accuracy |
AC Voltage |
15V/100V/300V/600V |
(1.2%+5) |
AC Current |
40A/100A/400A/1000A |
(2%+5) |
Active Power |
0.01kW-600kW |
(3%+5) |
Apparent Power |
0.01kVA-600kVA |
(3%+5) |
Reactive Power |
0.01kVAr-600kVAr |
(4%+5) |
Power Factor |
0.3~1(Capacitive or Inductive ) |
(0.02+2) |
Phase Angle |
0o~360O |
1O |
Frequency |
20Hz-500Hz |
√ |
Active Energy |
1~9999 kWh |
(3%+2) |
Temperature |
-50C~1300C |
3C |
Special Functions |
|
|
Auto Ranging |
|
√ |
Single-phase 2-wire |
|
√ |
3-phase 3-wire |
|
|
3-phase 4-wire |
|
|
True RMS |
AC Voltage or Curren |
√ |
Calibration Feature |
|
√ |
Data Logging |
99 |
√ |
Data Recall |
|
√ |
Max/Min Mode |
|
√ |
Data Hold |
|
√ |
USB |
|
√ |
Display Backlight |
EL |
√ |
Full Icon Display |
|
√ |
Sleep Mode |
|
√ |
Low Battery Display |
|
√ |
|
Input Impedance for AC Voltage Measurement |
Around 10MW |
√ |
Max. Display |
9999 |
√ |
Analogue Bar Graph |
|
√ |
